A
DMINISTRATION
Refer to the proper Management Unit Technical Practice for detailed Administration instructions.
For example:
1. Provision your PC/Laptop running Windows HyperTerminal or PROCOMM, etc. to the following terminal settings:
8 data bits
1 stop bit
no parity
VT-100 emulation
baud rate – 1200, 2400, 4800, 9600, 19200, 38400, 57600, 115200
2. Connect the DB-9 cable between the RS-232 port on the front of the Management Unit and the PC/Laptop
serial port.
3. Press several times until the Main Menu appears.
ENTER
