PERFORMANCE — HDSL 7 Day History (Continued)
Step
3 The following actions can be taken:
a. To view additional spans, select the SPAN field and press
press
ENTER
b. To clear the HDSL 7 Day History, select the CLEAR HISTORY FOR ALL SPANS button and press
. From the HDSL 7 DAY HISTORY WILL BE CLEARED. CONTINUE (Y/N)? prompt, the
ENTER
following actions can be taken:
• To clear the HDSL 7 Day History, press
1. all HDSL 7 day history 24-hour interval registers are set to zero and labeled UNA
2. current interval is labeled as ADJ
3. time and date that the registers were last cleared are updated
If there is an active 1-day ES or UAS alarm, this alarm becomes inactive when the
24-hour performance history is cleared and reactivates once the threshold has been crossed.
• To retain the existing HDSL 7 Day History, press
4
Press . The Main Menu screen reappears.
ESC
ADC Telecommunications, Inc.
.
Action
SPACEBAR
. The following events occur:
Y
.
N
SCP-FLL814-012-04H
to toggle to the other spans, then
