How to Connect a C-Nav3050 to the
C-NaviGator III
Section 2 - Serial connection
®
The C-Nav3050
GNSS receiver can be connected directly to a C-NaviGator III
using the supplied Y-Cable, Positronic 9-Pin Male to Ethernet RJ45 Plug & DB9S
(RS-232/1PPS) (P/N 94-310272-3006LFB) Or the alternative Y-Cable Positronic
9-Pin to USB & DB9(P/N NAV94-310273-3006LF C).
For full functionality the Green Y-cable with the RJ45 header should be
connected to COM1 and the Red Y-Cable with USB header is used with COM2.
Once these cables are attached to the C-Nav unit you then can pick either cable
to control the unit and connect it to the serial connection on the C-NaviGator II.
Revision 3
Page 8 of 31
4/13/2017
