How to Connect a C-Nav3050 to the
C-NaviGator III
Section 4 - Ethernet connection
®
The C-Nav3050 GNSS receiver can be connected directly to a C-NaviGator III
using the supplied Y-Cable, Positronic 9-Pin Male to Ethernet RJ45 Plug & DB9S
(RS-232/1PPS) (P/N 94-310272-3006LFB
The Green Y-Cable with RJ45 Ethernet header must be connected to the
receivers COM1 port for the Ethernet connection to be possible.
Ethernet connections made directly from the receiver to the NaviGator III via the
RJ45 head on the green Y-Cable connected to LAN port on the NaviGator III are
referred to as a 'Direct Ethernet Connection'.
Ethernet connections made directly from the receiver to the NaviGator III via the
RJ45 head on the green Y-Cable connected to LAN port on the NaviGator III are
referred to as a 'Direct Ethernet Connection'.
To set up the receiver it is required to make a connection via Serial or USB to
configure the network settings of the receiver, please see the earlier sections for
instructions on this.
