- Page 1 C-NavX3 Firmware Update Installation Manual CNAV-MAN-0066 Revision A ® C-Nav Positioning Solutions oceaneering.com/cnav...
- Page 2 C-Nav, C-Nav3050, C-Tides and C-Monitor are trademarks of Oceaneering International, Inc. “This document is the property of Oceaneering International and may not be used for any purpose unless authorized in writing by Oceaneering and which, upon demand, shall be returned. For any queries, related to Warranty and Limitation of liability, please contact your Accounts Manager for more information.”...
- Page 3 REFERENCES ..........................4 Symbols ............................. 5 OVERVIEW ............................5 Introduction ............................5 Recommended Setup ........................5 OBTAINING THE C-NAVX3 IP ADDRESS..................6 The C-NavX3 IP Address ........................6 THE C-NAVX3 FIRMWARE UPDATER ................... 7 The C-NavX3 Firmware Updater ....................... 7 CNAV-MAN-0066...
- Page 4 C-NavX3 Firmware Update Installation Manual INTRODUCTION This is a short tutorial explaining the steps necessary to update the firmware in a C-NavX3 GNSS receiver using the Windows updater application software. Sections are organized in a manner that facilitates quick operator orientation.
- Page 5 OVERVIEW Introduction The C-NavX3 GNSS receivers firmware update is performed over the receivers LAN connection. The update is sent to the receivers IP address before a restart is performed to finalize the update. Use only the latest version of software to perform the outlined procedure(s). The latest software...
- Page 6 5) Use the Query button to update the items on the menu window, if an IP address isn’t shown, give it some time and press Query again, else check the network hardware and cabling. 6) Take note of the IP address shown for the receiver, this will be the IP address entered on the C-NavX3 Firmware Updater Application.
- Page 7 1) Navigate to the C-Nav Customer Support webpage to download the latest version of C-NavX3 Firmware. 2) Unzip the contents of the file to find firmware, release notes and updater application. 3) Unzip the contents of ‘C-NavX3_v1.0.7.6.zip’ to reveal the ‘C-Nav X Firmware Updater.zip’ file. Unzip the contents to reveal the 3 files for the C-Nav X.
- Page 8 C-NavX3 Firmware Update Installation Manual 5) Followed by Run anyway. 6) On the final prompt select Install. CNAV-MAN-0066 Senior Manager, C-Nav DOC-TEM-28-NUM Rev A Uncontrolled copy when printed Revision A Page 8 of 13...
- Page 9 C-NavX3 Firmware Update Installation Manual 7) The C-NavX3 Firmware Updater window will open, there is a Help button in the top right which provides an in-application option for instructions. 8) Toggle the C-Nav Unit radio button to X3. – Obtaining the C-NavX3...
- Page 10 C-NavX3 Firmware Update Installation Manual 10) Press Select File to browse to the location of the C-NavX3 firmware. The C-NavX3 firmware file extension will end with *.itb. 11) The file can either be double clicked or selected and Open pressed.
- Page 11 12) With the Target Unit IP address populated and the Select File completed use the Transfer button to send the update to C-NavX3 unit. The progress will update in the Log portion of the application. 13) Following a successful transfer, press Update.
- Page 12 C-NavX3 Firmware Update Installation Manual 14) After successful update, the C-NavX3 will reboot automatically. Once, the update is complete, the LED’s will be illuminated. CNAV-MAN-0066 Senior Manager, C-Nav DOC-TEM-28-NUM Rev A Uncontrolled copy when printed Revision A Page 12 of 13...
- Page 13 17) Confirm that the reported firmware version corresponds to the version number of the selected firmware update. WARNING: You will not be able to connect to the C-NavX3 until the GNSS status LED is green. CNAV-MAN-0066 Senior Manager, C-Nav DOC-TEM-28-NUM Rev A Uncontrolled copy when printed...
