Contents
Important User Information . . . . . . . . . . . . . . . . . . . . . . . . . . .2
General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Manufacturer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Intended Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Safety Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Required Tools. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Rigging Equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Fasteners. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Tower Assembly Description . . . . . . . . . . . . . . . . . . . . . . . . . .6
Tower Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Before Starting the Tower Installation . . . . . . . . . . . . . .7
Assemble the Tower Frame . . . . . . . . . . . . . . . . . . . . . .8
Assemble the Center Panels . . . . . . . . . . . . . . . . . . . . .9
Attach Trim to the Center Panels . . . . . . . . . . . . . . . . . .11
Seperate Lower Filler Panel . . . . . . . . . . . . . . . . . . . . . .12
Attach Frame to the Center Panels . . . . . . . . . . . . . . . .13
Attach Base . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Attach Wing Panels . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Attach Leveler Assembly . . . . . . . . . . . . . . . . . . . . . . . .19
Attach Wing Stays . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
Attach Slide Lock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
Attach Door Pull Handle . . . . . . . . . . . . . . . . . . . . . . . . .24
Lifting Tower . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
Install Counterweights . . . . . . . . . . . . . . . . . . . . . . . . . .27
Attach Base Handle . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
Store Lower Filler Panel . . . . . . . . . . . . . . . . . . . . . . . . .29
Attach Lower Filler Panel . . . . . . . . . . . . . . . . . . . . . . . .30
Moving Towers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31
Decals, Numbers and Logos . . . . . . . . . . . . . . . . . . . . . . . . .32
Final Inspection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32
Visit the Diva Acoustical Shell web page at www.wengercorp.com
for detailed instructions and videos.
Note: Please read and understand these instructions before installing.
Note: Review all of the Installation Drawings and Reference Drawings.
Note: Three or more people are recommended to work together during assembly and installation.
Note: If you need additional information, contact Wenger Corporation using the information below.
©Wenger Corporation 2017
Wenger Corporation, 555 Park Drive, P.O. Box 448, Owatonna, Minnesota 55060-0448
Questions? Call.....USA: (800) 4WENGER (493-6437) • Worldwide: +1(507) 455-4100 • www.wengercorp.com
Diva
Printed in USA 06/17
Installation Instructions
Acoustical Tower
®
Part #185C755-02
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Wenger Diva
Summary of Contents for Wenger Diva
-
Page 1: Table Of Contents
Note: Review all of the Installation Drawings and Reference Drawings. Note: Three or more people are recommended to work together during assembly and installation. Note: If you need additional information, contact Wenger Corporation using the information below. ©Wenger Corporation 2017... -
Page 2: Important User Information
(800) 4WENGER (493-6437) • +1 (507) 455-4100 www.wengercorp.com Intended Use · The Diva Acoustical Tower is intended for indoor use only and is not intended for outdoor use. · Never expose the Diva Acoustical Tower components to wind, humidity, or wet conditions. ·... -
Page 3: Safety Precautions
WARNING WARNING WARNING Make sure that anyone Failure to comply with Always observe and comply working with the Diva Warnings and Cautions in with the Warnings and Acoustical Tower has read this document can result Cautions posted on the and understands these in damage to property or system equipment. -
Page 4: Rigging Equipment
Rigging Equipment The installers must supply the following rigging equipment for the Acoustical Tower Installation. · · Wing Harnesses 1-ton Invertable Hoist · Span Set Slings · Locking Clamps · Lifting Casters Wing Harnesses Lifting Casters Span Set Slings Locking Clamps 1-ton Invertable Hoist... -
Page 5: Fasteners
Fasteners The fasteners shown below are contained in various Diva hardware kits. Any fasteners remaining when an the installation is complete should be discarded. Carriage Bolt, 1/2-13 x 4” Button Head Screw, 3/8-16 x 1” Hex Head Screw, 1/2-13 x 2”... -
Page 6: Tower Assembly Description
Tower Assembly Description The following illustration describes components used in the Diva Acoustical Tower Assembly. Fixed Hinge — Bracket that is used to attach the Center Panels to the Vertical Frame. Center Panels — A set of two or more Panels that are fixed at the center of the assembly. -
Page 7: Tower Installation
4. Make sure that all items on the shipment packing list are present. Note: The paragraphs on the following pages describe the assembly and installation of a 16’ tower assembly. All Diva Acoustical Shell assemblies are installed in the same way. CAUTION To avoid damage to surfaces: •... -
Page 8: Assemble The Tower Frame
Tower Installation (continued) The following procedure is described using a 16’ tall Diva Tower. Taller towers are assembled using the same steps but may need to be spliced together. Refer to the installation drawings. Assemble the Tower Frame 1. Assemble the Tower Frame as shown. -
Page 9: Assemble The Center Panels
Tower Installation (continued) Assemble the Center Panels Refer to the installation drawings for Center Panel placement. 1. Sweep the floor around the assembly area and place the 4’ x 8’ sheets of cardboard that shipped with the tower onto the floor surface to protect the panel surfaces. 2. - Page 10 Tower Installation (continued) Assemble the Center Panels (continued) 5. Connect the Upper Center Panel and Lower Center Panel together. a. Slide the panels together and align the edges. b. Connect the two Panel Inner Clips together using a 1/4-20 x 3-1/2” Carriage Bolt and 1/4-20 Lock Nut.
-
Page 11: Attach Trim To The Center Panels
Tower Installation (continued) Attach Trim to the Center Panels 1. Align Trim Strips of matching lengths to both sides of all of the Center Panels. The ends of the Trim Strips should match with the gaps between the Panels. 2. Attach the Trim Strips to the Panels using 1/4-20 x 1” Self-drilling Screws as shown. Trim Strip 1/4-20 x 1”... -
Page 12: Seperate Lower Filler Panel
Tower Installation (continued) Seperate Lower Filler Panel 1. Seperate the Lower Filler Panel from the Lower Center Panel by removing the bracket and two screws that secure each side. 2. Flip the Hasp up to release the Hook. 3. Slide the Lower Filler Panel away and set it aside. Flip Hasp up Screws Lower Filler... -
Page 13: Attach Frame To The Center Panels
Tower Installation (continued) Attach Frame to the Center Panels 1. Place the Tower Frame Assembly onto the Center Panels. Position the Weldment Bar on the Frame Assembly to be near the Door Latch on the Lower Panel. Be sure not to trap the Hinges of the Tower Frame inside of the Trim at the edges of the Center Panels. - Page 14 Tower Installation (continued) Attach Frame to the Center Panels (continued) 2. Place wood blocks (that were saved from the packaging) under both sides of the Frame Asssembly to hold it steady and to keep pressure off of the Panels. The wood blocks must be at even heights on both sides and positioned to not extend beyond the edge of the Frame as shown.
-
Page 15: Attach Base
Tower Installation (continued) Attach Base 1. Attach the Base Asssembly to the bottom of the Tower Frame using four 3/8-20 x 1” Capscrews and 3/8-16 Lock Nuts on each side. Only hand tighten the fasteners at this time. 3/8-16 x 1” Capscrews 3/8-16 Lock Nuts... - Page 16 Tower Installation (continued) Attach Base (continued) 3. Attach the Brace Rods. First, slide Brace Rod through the Base a. Slide a Brace Rod into the Base and then into the Lower Cross Brace as shown. Brace Then through the Lower Cross Brace b.
-
Page 17: Attach Wing Panels
Tower Installation (continued) Attach Wing Panels Refer to the installation drawings for Wing Panel placement. 1. Sweep the floor around the assembly area and place 4’ x 8’ sheets of cardboard onto the floor surface to protect the panel surface. 2. - Page 18 Tower Installation (continued) Attach Wing Panels (continued) 4. Align the seam of the adjacent Wing Panels with the seam of the Center Panels. The panels should also be aligned along the top edge. 5. Attach the Wing Panels to the Tower Frame. a.
-
Page 19: Attach Leveler Assembly
Tower Installation (continued) Attach Leveler Assembly 1. Attach the two Leveler Assemblies to the bottom of the Base. a. Turn the 1-8 Hex Jam Nut on both Leveler Assemblies to be at the same height. b. Turn each Leveler Assembly onto the Base until the Jam Nut contacts the bottom of the Base. -
Page 20: Attach Wing Stays
Tower Installation (continued) Attach Wing Stays 1. Assemble both the Right and Left Wing Stays. a. Remove the Capscrew from the top slot in both Wing Stay Channels. b. The Wing Stays must be fully extended as shown. c. Screw a Wing Stay Tube into the bottom of the Wing Stay Channel to be hand tight. Remove Capscrew Wing Stay... - Page 21 Tower Installation (continued) Attach Wing Stays (continued) 3. Attach both Wing Stay Assemblies to the Wing Base Bracket on each side using one 5/16-18 x 1-3/8” Capscrew and 5/16-18 Nylon Insert Lock Nut. 5/16-18 Nylon Insert Lock Nut 5/16-18 x 1-3/8” Capscrew...
- Page 22 Tower Installation (continued) Attach Wing Stays (continued) 4. Attach both Wing Stays to the Wing Panels. a. Twist the Wing Stay Tube to loosen and fully extend the Wing Stay. b. With the Wing Stay fully extended, place the Wing Stay Plate onto the inside of the Wing Panel.
-
Page 23: Attach Slide Lock
Tower Installation (continued) Attach Slide Lock 1. Attach the Slide Lock to an Access Door Wing Panel. a. Position the Slide Lock Assembly to be approximately 3-1/2” from the outer edge of the Access Door Panel and 1/4” from the top of the panel. b. -
Page 24: Attach Door Pull Handle
Tower Installation (continued) Attach Door Pull Handle 1. Attach the Door Pull Handle to an Access Door Wing Panel. a. Position the Handle to be approximately 3-1/2” from the outer edge of the Access Door Panel and 37” from the bottom of the panel. b. -
Page 25: Lifting Tower
Tower Installation (continued) Lifting Tower Lift the Tower Assembly to stand upright. 1. Secure the Lifting Casters to both Casters with Locking Clamps (see photo 1 on the following page). 2. Fold up the Wing Panels on both sides. Wrap a chain around the Diagonal Brace and connect it to the edge of the Wing Panel using a Hook, Clamp and Locking Clamps (see photo 2 on the following page). - Page 26 Tower Installation (continued) Lifting Tower (continued) Photo 1 Photo 2 Photo 3a Photo 3b...
-
Page 27: Install Counterweights
Tower Installation (continued) Install Counterweights 1. Place Counterweights into the Base. Consult the installation drawings for required quantities and weights. CAUTION Counterweights are heavy, use appropriate lifting techniques. 2. Attach the Counterweight Cover to the Base using four 1/4-20 x 3/4” Tapping Screws. 3. -
Page 28: Attach Base Handle
Tower Installation (continued) Attach Base Handle 1. Attach a Base Handle to the Base Assembly using two 1/4-20 x 1” Self-drilling Screws. Base Handle 3/4-20 x 1” Tapping Screws... -
Page 29: Store Lower Filler Panel
Tower Installation (continued) Store Lower Filler Panel 1. To store the Lower Filler Panel: a. Insert the Retention Cord through the empty hole in both Vertical Tower Frames as shown. Tie a knot in both ends to secure it to the Tower Frames. b. -
Page 30: Attach Lower Filler Panel
Tower Installation (continued) Attach Lower Filler Panel 1. Attach the Lower Filler Panel to the Tower Assembly by sliding it into position from the outside surface of the tower. 2. Flip the Hook on the filler panel over the Hasp on the Center Panel and rotate it upward to close. -
Page 31: Moving Towers
Tower Installation (continued) Moving Towers A separate Manual Wheeled Mover or Electric Air Transporter is required to lift and move Diva Towers. CAUTION CAUTION Never use the Wheeled Mover Never attempt to manually lift or Air Transporter for any or move a Diva Tower without... -
Page 32: Decals, Numbers And Logos
Decals, Numbers and Logos 1. Place a Tower Operation Decal onto the Back Side of a Door Panel or Wing Panel (place one decal on each Tower Assembly) near the outer edge and with the bottom of the decal about 54” from the floor. 2.
