Wenger Diva Installation Instructions Manual

Acoustical ceiling
Hide thumbs Also See for Diva:

Advertisement

Quick Links

Download this manual
CONTENTS
Important User Information . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Safety Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Required Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Fasteners . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Visit the Diva web page at www.wengercorp.com for detailed instructions and videos.
Note: Please read and understand these instructions before installing the Diva
Note: Review all of the Installation Drawings that were created for the Diva
Installation.
Note: It is recommended that three or more people work together during the assembly.
Note: Refer to the illustrations on the following pages. If you need additional information,
contact the Wenger Corporation using the information below.
©Wenger Corporation 2014
Wenger Corporation, 555 Park Drive, P.O. Box 448, Owatonna, Minnesota 55060-0448
Questions? Call.....USA: 1-800-4WENGER (493-6437) • Worldwide: 1-507-455-4100 • www.wengercorp.com
Diva
Ceiling Assembly Description . . . . . . . . . . . . . . . . . . . . . . . . .5
Ceiling Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Decals, Numbers and Logos . . . . . . . . . . . . . . . . . . . . . . . . .28
Final Inspection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
Printed in USA 01/14
Installation Instructions
Acoustical Ceiling
®
Acoustical Ceiling.
®
Acoustical Ceiling
®
Part #185C756-01

Advertisement

loading
Need help?

Need help?

Do you have a question about the Diva and is the answer not in the manual?

Questions and answers

Related Manuals for Wenger Diva

Summary of Contents for Wenger Diva

  • Page 1: Table Of Contents

    Visit the Diva web page at www.wengercorp.com for detailed instructions and videos. Note: Please read and understand these instructions before installing the Diva Acoustical Ceiling. ® Note: Review all of the Installation Drawings that were created for the Diva Acoustical Ceiling ® Installation.

  • Page 2: Important User Information

    555 Park Drive Owatonna, MN 55060 1-507-455-4100 • 1-800-733-0393 www.wengercorp.com NTENDED The Wenger Diva Acoustical Ceiling is intended for indoor use and is not intended for outdoor use. Never expose the components to wind, humidity, or wet conditions. • • NSTALLATION The installation must comply with local regulations and codes.

  • Page 3: Safety Precautions

    EQUIRED OOLS The following tools are required for the Diva Acoustical Tower Installation. Assorted Wrenches ”, ” and ” Drive Sockets Cordless Drill and Cordless Impact Driver ” Deep Well Socket and Drive Adapter •...

  • Page 4: Fasteners

    ASTENERS The fasteners shown below are contained in various Diva Acoustical Ceiling hardware kits. ® Any fasteners remaining when an the installation is complete can be discarded. Carriage Bolt, -13 x 4” Button Head Screw, -16 x 1” Hex Head Screw, -13 x 2”...

  • Page 5: Ceiling Assembly Description

    EILING SSEMBLY DESCRIPTION The following illustration describes components used in the Diva Acoustical Ceiling. Lift Line — Stage Rigging Lift Line. Batten — Stage Rigging Pipe Batten. Turnbuckle Assembly — Used to level the Ceiling Assembly. Hanger Arm Assembly — Connects the Ceiling Assembly to the Stage Rigging.

  • Page 6: Ceiling Installation

    Note: The weight of each Ceiling Assembly is calculated and does not include the weight of the rigging or rigging hardware. Note: Unless specifically agreed by Wenger Corporation, all rigging and rigging hardware is furnished by the general contractor or facility owner.
  • Page 7 Self-drilling Screw, Truss Cap -14x ” Upstage Truss Splice Bar First Truss Self-drilling Screw, Truss -14x ” Splice Find and mark the center location on the Truss Assembly. Additional Truss Truss Truss Assembly...
  • Page 8 EILING NSTALLATION CONTINUED ARK THE TAGE 1. Mark the centerline of the Stage as follows. Refer to the illustration below. a. Make sure that the Line Sets are in the correct position. b. Mark the mid point downstage between the two sides of the proscenium. c.
  • Page 9 EILING NSTALLATION CONTINUED TTACH THE ANGER RMS TO THE ATTEN Note: Always refer to the Installation Drawings for the location and arrangement of components. 1. Lower the Batten to a working height. 2. Attach a Hanger Assembly to the Batten 1” to 2” from each Line-set as follows. a.
  • Page 10 EILING NSTALLATION CONTINUED TTACH THE ANGER RMS TO THE ATTEN ( CONTINUED 3. continued... e. Using a pair of ” combination wrenches, re-attach the Pipe Clamp to the Turnbuckle Upper Jaw with the Locknut and Screw set aside in step 2b. Attach other Turnbuckle Assemblies to the Batten by repeating steps 2a to 2e.
  • Page 11 EILING NSTALLATION CONTINUED TTACH THE ANGER RMS TO THE RUSS SSEMBLY 1. Attach the Hanger Assemblies to the Ceiling Truss. a. Remove a Hanger Assembly from the Hanger Kit Hardware Bag. b. Unscrew the two Locknuts and remove the Carriage Bolt and the Hex Head Screw. Save the Hanger Straps, Locknuts, Carriage Bolt, and Screw.
  • Page 12 EILING NSTALLATION CONTINUED TTACH THE ANGER RMS TO THE RUSS SSEMBLY ( CONTINUED 2. Connect the Hanger Arms to the Ceiling Row Truss Assembly. a. Lower the Batten and Hanger Arms until the each Hanger Arm Lower Eye will fit into each Hanger Assembly as shown in the illustration below. b.
  • Page 13 EILING NSTALLATION CONTINUED SSEMBLE A EILING ANEL Assemble a Ceiling Panel Row as follows. Note: Always refer to the Installation Drawings for the location and arrangement of Ceiling Panels. 1. To prevent damage, lay the Ceiling Panels on 4’ x 8’ sheets of packing material. Make sure that the Ceiling Panels are arranged below the Batten with about a 4”...
  • Page 14 EILING NSTALLATION CONTINUED SSEMBLE A EILING ANEL OW ( CONTINUED 3. Connect two adjacent Ceiling Panels together. Refer to the illustrations below. a. Insert a Carriage Bolt ( -20 x 3 ”) through the square hole in a Panel Inner Corner Clip, through the two Outer Corner Clips, and through the other Panel Inner Corner Clip.
  • Page 15 EILING NSTALLATION CONTINUED TTACH THE RUSS SSEMBLY TO THE EILING ANEL Refer to the illustration below and follow the Installation Drawings for proper location. 1. Place the Truss Assembly onto the Ceiling Panel Center Channel. a. Make sure that the Truss Assembly is centered over the Ceiling Panel Center Channel. Ceiling Panel Row Truss Assembly...
  • Page 16 EILING NSTALLATION CONTINUED TTACH THE RUSS SSEMBLY TO THE EILING ANEL OW ( CONTINUED 2. Use a rubber mallet to seat each Hanger Bracket onto the Ceiling Panel Center Channel. Note: Each Hanger Bracket Assembly faces the upstage side and must be centered on the Seam between two adjacent Ceiling Panels.
  • Page 17 EILING NSTALLATION CONTINUED SSEMBLE THE OWSTRING TO THE RUSS 1. Attach a Bowstring Assembly to a Ceiling Panel as follows. Begin at one end of the Ceiling Panel Row. a. Using a Hex Head Screw, -16 x 2 ”, and a Locknut, -16, attach the Bowstring Jack to the Bowstring as shown in the illustration below.
  • Page 18 EILING NSTALLATION CONTINUED SSEMBLE THE OWSTRING TO THE RUSS ( CONTINUED 2. Position the Ceiling Clips flush with the outer edge of the Ceiling Panel. Make sure neither Ceiling Clip extends beyond the Ceiling Panel edge. Refer to the illustration below. Using a cordless drill and the ”...
  • Page 19 EILING NSTALLATION CONTINUED PPLY ENSION TO THE OWSTRING WARNING Do not load weights onto the Arbor until tension is applied to all of the Bowstrings. 1. Lift a Bowstring upward by hand to remove any slack. 2. While lifting the Bowstring, turn the Hex Jam Nut, 1-8, clockwise as shown below until the Jam Nut is snug against the Jack Tube.
  • Page 20 EILING NSTALLATION CONTINUED NSTALL THE EILING TAYS Refer to the Installation Drawings and determine where each Ceiling Stay Assembly must be installed. 1. Remove and set aside the Hex Head Screw, Washer, and Locknut from the Ceiling Stay Base Bracket. Hex Head Screw Washer Locknut...
  • Page 21 EILING NSTALLATION CONTINUED NSTALL THE EILING TAYS ( CONTINUED 3. Attach the Ceiling Stay End Bracket to the Ceiling Panel. a. Extend the Ceiling Stay Rod so that the Ceiling Stay End Bracket is flush with the edge of the Ceiling Panel as shown below. b.
  • Page 22 EILING NSTALLATION CONTINUED LY THE EILING SSEMBLY WARNING WARNING Only qualified personnel who are Make sure that all rigging and rigging hardware is familiar with rigging systems should capable of lifting the Ceiling Panel component set up the rigging, add weights to calculated weight plus a reasonable margin of safety.
  • Page 23 EILING NSTALLATION CONTINUED EVEL THE EILING SSEMBLY 1. Position the Ceiling Panel Row 4’ to 5’ from the floor surface. 2. Use a box level and check the length of the Ceiling Panel Row and make sure that it is straight and level.
  • Page 24 EILING NSTALLATION CONTINUED ET THE EILING ERFORMANCE NGLE Refer to the Installation Drawings when setting the Ceiling Stay Performance Angle. 1. Rotate the Ceiling Panel Row into the storage (vertical) position. 2. Use a pair of ” combination wrenches to loosen (finger tight) all of the Hex Head Screws (four) and Locknuts on the Latch Receiver Assembly.
  • Page 25 EILING NSTALLATION CONTINUED NSTALL THE EILING ATCH Refer to the Installation Drawings for the Ceiling Catch location. 1. Remove a Ceiling Catch Assembly from the shipping container. 2. Remove the two Locknuts from the U-bolt, remove the U-bolt from the Ceiling Ceiling Catch Catch Pivot Plate, and set the U-bolt and Locknuts aside.
  • Page 26 EILING NSTALLATION CONTINUED EILING ANEL IGHT SSEMBLY Install Ceiling Panel Light Assemblies into the pre-cut Ceiling Panel Holes. Refer to the Installation Drawings for locations. WARNING A licensed electrician must perform the electrical installation. Branch circuits that connect to Ceiling Panel Lights must always be designed by an electrical engineer and comply with electrical codes and user requirements.
  • Page 27 EILING NSTALLATION CONTINUED EILING ANEL IGHT SSEMBLY ( CONTINUED 4. Connect the Ceiling Panel Light Power Cord to a grounded, fused, three-wire, 120VAC, 25 ampere power source with a twist-lock receptacle. The power source must comply with local electrical codes. Ceiling Panel Light Assembly Ceiling Panel Panel...

  • Page 28: Decals, Numbers And Logos

    ECALS UMBERS AND OGOS 1. Place a Ceiling Operation Decal near each Ceiling Stay approximately 2” from the Upstage Edge. INAL INSPECTION 1. Check the rigging. a. Make sure that it operates smoothly and safely. b. Determine if additional weights need to be added to any arbors to offset the additional weight of Ceiling Stays, Lights, etc.
