Wenger Drawer Kit Installation Instructions Manual

Accessory for the studio makeup station

Advertisement

Make sure anyone assembling, installing or
using these products has read and understands
these instructions.
Contents
Supplied Hardware � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 2
Parts List � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 2
Required Tools� � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 2
Visit the Studio Makeup Station web page at wengercorp.com for more information.
Note: Please read and understand these instructions before proceeding�
Note: If you need additional information, contact Wenger Corporation using the information below�
©Wenger Corporation 2024
Wenger Corporation, 555 Park Drive, P�O� Box 448, Owatonna, Minnesota 55060-0448
Questions? Call�����USA: (800) 4WENGER (493-6437) • Worldwide: +1-507-455-4100 • wengercorp�com
Basic Instructions only!
For more detailed product information, refer to the
Studio Makeup Station Owner's Manual 187A205.
CAUTION
Studio Makeup Station
with Drawer Kit Accessory
Drawer Kit Accessory
for the Studio
Failure to comply with Warnings and Cautions in
this document or on the equipment can result in
damage to property or injury.
Before Starting the Assembly � � � � � � � � � � � � � � � � � � � � � � � � � � � � 3
Drawer Installation � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 4
Printed in USA 2024-10
Installation Instructions
Makeup Station
®
CAUTION
Part #187A144-03

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Drawer Kit and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Wenger Drawer Kit

  • Page 1: Table Of Contents

    Visit the Studio Makeup Station web page at wengercorp.com for more information. Note: Please read and understand these instructions before proceeding� Note: If you need additional information, contact Wenger Corporation using the information below� ©Wenger Corporation 2024 Printed in USA 2024-10 Part #187A144-03 Wenger Corporation, 555 Park Drive, P�O�...
  • Page 2: Supplied Hardware

    Supplied Hardware 3/4" 3/4" #8 x 3/4" #10 x 3/4" Phillips Flat Head Phillips Pan Head Sheet Metal Screw Sheet Metal Screw Parts List Item Qty Description Drawer L-bracket** #10 x 3/4" Phillips Pan Head Sheet Metal Screw** #8 x 3/4" Phillips Flat Head Sheet Metal Screw** Lock Assembly Key Set (not shown)** **Contained in the hardware kit bag Required Tools...
  • Page 3: Before Starting The Assembly

    Before Starting the Assembly Before installing the studio makeup station drawer option, do the following� 1� Read and understand this entire installation instruction� 2� Open the shipping container and make sure that it contains a drawer and a hardware pack with one L-bracket, a set of keys for the lock, nine pan head screws and three flat head screws.
  • Page 4: Drawer Installation

    Drawer Installation 1� Locate the ten pre-drilled pilot holes on the bottom-right and bottom-left side of the counter� Choose the right or left side of the counter for the drawer assembly� Pilot Holes Counter Bottom Surface 3� Remove both drawer glide slide assemblies from the drawer as follows� a�...
  • Page 5 Drawer Installation (continued) 4� Align the mounting holes of a drawer glide slide assembly to a set of pilot holes on the bottom side of the counter. Make sure that the bracket flange faces the main frame and that the glide opens outward. WARNING Never remove the counter to install the drawer.
  • Page 6 Drawer Installation (continued) 6� Attach the L-bracket to the counter by screwing two #8 x 3/4" flat head screws into the two lock bracket pilot holes� Make sure that the flange faces the outside edge of the counter. NOTICE The L-bracket may need to be adjusted in or out to fully engage the lock.
  • Page 7 This page is intentionally blank�...
  • Page 8 This page is intentionally blank�...
