Wenger Diva Installation Instructions Manual

Acoustical ceiling
Hide thumbs Also See for Diva:
Table of Contents

Advertisement

Quick Links

Download this manual
Contents
Important User Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Safety Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Required Tools. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Fasteners. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Ceiling Assembly Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Before Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Ceiling Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Assemble the Truss . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Mark the Stage Area . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Attach the Hanger Arms to the Batten . . . . . . . . . . . . . . . . . 9
Assemble a Ceiling Row Panel . . . . . . . . . . . . . . . . . . . . . . . 14
Assemble the Bowstring to the Truss . . . . . . . . . . . . . . . . . . 18
Apply Tension to the Bowstring . . . . . . . . . . . . . . . . . . . . . . . 20
Install the Ceiling Stays . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Fly the Ceiling Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Level the Ceiling Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Set the Ceiling Stay Performance Angle . . . . . . . . . . . . . . . . 25
Install the Ceiling Catch . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Visit the Diva Acoustical Shell web page at wengercorp.com for more information.
Note: Please read and understand these instructions before using or setting up.
Note: Review all of the Installation Drawings and Reference Drawings.
Note: It is recommended that three or more people work together during the assembly.
Note: If you need additional information, contact Wenger Corporation using the information below.
©Wenger Corporation 2020
Wenger Corporation, 555 Park Drive, P.O. Box 448, Owatonna, Minnesota 55060-0448
Questions? Call.....USA: (800) 4WENGER (493-6437) • Worldwide: +1-507-455-4100 • wengercorp.com
Diva
®
Light Fixture Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Inspection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Lieto LED Light Fixture Installation . . . . . . . . . . . . . . . . . . . . 28
Light Fixture Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Initial Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Configure the DMXcat Connection . . . . . . . . . . . . . . . . . . . . 31
Lieto LED Light Fixture Communication . . . . . . . . . . . . . . . . 31
DMX Address Information . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
LED Power Settings Chart . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Light Fixture Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Adjustment and Aiming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Photometrics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Schematics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
(Diva Acoustical Ceiling) . . . . . . . . . . . . . . . . . . . . . . . . 36
Decals, Numbers and Logos . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Final Inspection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Printed in USA 2020-05
Installation Instructions
Acoustical Ceiling
Part #185C756-05

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Diva and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Wenger Diva

Summary of Contents for Wenger Diva

  • Page 1: Table Of Contents

    Fly the Ceiling Assembly ......23 (Diva Acoustical Ceiling) ......36 Level the Ceiling Assembly .

  • Page 2: Important User Information

    Wenger Corporation. Wenger Corporation does not assume any responsibility for any errors that may appear in these instructions. In no event will Wenger Corporation be liable for technical or editorial omissions made herein, nor for direct, indirect, special, incidental, or consequential damages resulting from the use or defect of these instructions.

  • Page 3: Safety Precautions

    Make sure that anyone working Failure to comply with Warnings Always observe and comply and Cautions in this document with the Diva Acoustical Ceiling with the Warnings and can result in damage to property has read and understands these Cautions posted on the system or serious injury.

  • Page 4: Fasteners

    Fasteners The fasteners shown below are contained in various Diva hardware kits. Any fasteners remaining when an the installation is complete can be discarded. Button Head Screw, Carriage Bolt, 1/2-13 x 4" 3/8-16 x 1" Hex Head Screw, 1/2-13 x 2"...

  • Page 5: Ceiling Assembly Description

    Ceiling Assembly Description Lift Line Stage rigging lift line. Batten Stage rigging pipe batten. Turnbuckle Assembly Used to level the ceiling assembly. Hanger Arm Assembly Connects the ceiling assembly to the stage rigging. Ceiling Panel Provides the sound reflective surface for the ceiling assembly. Bowstring Structural component used to suspend the ceiling panel when...

  • Page 6: Before Installation

    Before Installation Note: The weight of each ceiling assembly is calculated and does not include the weight of the rigging or rigging hardware. Note: Unless specifically agreed by Wenger Corporation, all rigging and rigging hardware is furnished by the general contractor or facility owner. CAUTION WARNING WARNING Personnel must always wear a...

  • Page 7: Ceiling Installation

    Ceiling Installation Always refer to the installation drawings for the location and arrangement of STOP ceiling panels. Assemble the Truss 1. Assemble the first truss assembly under the batten or cables as follows. a. Attach a truss splice into the lower channel of the truss using one 1/4-14 x 3/4" self-drilling screw on the upstage side. Tighten only finger tight until all screws are installed.

  • Page 8: Mark The Stage Area

    Ceiling Installation (continued) Mark the Stage Area 1. Mark the centerline of the stage as follows. Refer to the illustration below. a. Make sure that the line sets are in the correct position. b. Mark the mid point downstage between the two sides of the proscenium. Measure an equal distance from the two sides of the proscenium and mark the mid point upstage as shown in the illustration below.

  • Page 9: Attach The Hanger Arms To The Batten

    Ceiling Installation (continued) Attach the Hanger Arms to the Batten Note: Always refer to the installation drawings for the location and arrangement of components. 1. Lower the batten to a working height. 2. Attach hanger assemblies to the batten at the locations indicated on the installation drawings as follows. a.
  • Page 10 Ceiling Installation (continued) Attach the Hanger Arms to the Batten (continued) 2. continued... d. At the proper locations, attach the pipe clamp to the batten using two hex head screws and tighten securely. Lift Line Pipe Clamp Batten Pipe Clamp Pipe Clamp Batten e.
  • Page 11 Ceiling Installation (continued) Attach the Hanger Arms to the Batten (continued) 3. Attach a hanger arm to each turnbuckle assembly as follows. a. Remove the lock nut and hex head screw form a turnbuckle lower jaw. Set aside the lock nut and screw. b.

  • Page 12: Attach The Hanger Arms To The Truss Assembly

    Ceiling Installation (continued) Attach the Hanger Arms to the Truss Assembly 1. Attach the hanger assemblies to the ceiling truss. a. Remove a hanger assembly from the hanger kit hardware bag. b. Unscrew the two lock nuts and remove the carriage bolt and the hex head screw. Save the hanger straps, lock nuts, carriage bolt, and screw.
  • Page 13 Ceiling Installation (continued) Attach the Hanger Arms to the Truss Assembly (continued) 2. Connect the hanger arms to the ceiling row truss assembly. a. Lower the batten and hanger arms until the each hanger arm lower eye will fit into each hanger assembly as shown in the illustration below. b. Attach a hanger arm lower eye to a hanger assembly with the hex head screw and lock nut set aside in step 1b on the previous page.

  • Page 14: Assemble A Ceiling Row Panel

    Ceiling Installation (continued) Assemble a Ceiling Row Panel Assemble a ceiling panel row as follows. Note: Always refer to the installation drawings for the location and arrangement of ceiling panels. 1. To prevent damage, lay the ceiling panels on 4' x 8' sheets of packing material. Make sure that the ceiling panels are arranged below the batten with about a 4"...
  • Page 15 Ceiling Installation (continued) Assemble a Ceiling Panel Row (continued) 3. Connect two adjacent ceiling panels together. Refer to the illustrations below. a. Insert a 1/4-20 x 3-1/2" carriage bolt through the square hole in a panel inner corner clip, through the two outer corner clips, and through the other panel inner corner clip. b.

  • Page 16: Attach The Truss Assembly To The Ceiling Panel Row

    Ceiling Installation (continued) Attach the Truss Assembly to the Ceiling Panel Row Refer to the illustration below and follow the installation drawings for proper location. 1. Place the truss assembly onto the ceiling panel center channel. a. Make sure that the truss assembly is centered over the ceiling panel center channel. Ceiling Panel Row Truss Assembly...
  • Page 17 Ceiling Installation (continued) Attach the Truss Assembly to the Ceiling Panel Row (continued) 2. Use a rubber mallet to seat each hanger bracket onto the ceiling panel center channel. Note: Each hanger bracket assembly faces the upstage side and must be centered on the seam between two adjacent ceiling panels.

  • Page 18: Assemble The Bowstring To The Truss

    Ceiling Installation (continued) Assemble the Bowstring to the Truss 1. Attach a bowstring assembly to a ceiling panel as follows. Begin at one end of the ceiling panel row. a. Using a 3/8-16 x 2-1/4" hex head screw, and a 3/8-16 lock nut, attach the bowstring jack to the bowstring as shown in the illustration below.
  • Page 19 Ceiling Installation (continued) Assemble the Bowstring to the Truss (continued) 2. Position the ceiling clips flush with the outer edge of the ceiling panel. Make sure neither ceiling clip extends beyond the ceiling panel edge. Refer to the illustration below. 3 Using a cordless drill and the 9/32" drill bit, drill holes into the rear flange of the panel extrusion using the ceiling clip mounting holes as a template for the drill bit. Do not drill through the to face of the panel. 4. Using a 1/2" open end wrench, screw two tapping screws into the 9/32" holes in the rear flange of the ceiling panel extrusion drilled in step 3.

  • Page 20: Apply Tension To The Bowstring

    Ceiling Installation (continued) Apply Tension to the Bowstring WARNING Do not load weights onto the Arbor until tension is applied to all of the Bowstrings. 1. Lift a bowstring upward by hand to remove any slack. 2. While lifting the bowstring, turn the hex jam nut, 1-8, clockwise as shown below until the jam nut is snug against the jack tube.

  • Page 21: Install The Ceiling Stays

    Ceiling Installation (continued) Install the Ceiling Stays Refer to the installation drawings and determine where each ceiling stay assembly must be installed. 1. Remove and set aside the hex head screw, washer, and lock nut from the ceiling stay base bracket. Hex Head Screw Washer Lock Nut...
  • Page 22 Ceiling Installation (continued) Install the Ceiling Stays (continued) 3. Attach the ceiling stay end bracket to the ceiling panel. a. Extend the ceiling stay rod so that the ceiling stay end bracket is flush with the edge of the ceiling panel as shown below. b. Use a cordless drill and a 3/8" hex bit and screw a #10-16 x 0.75" self-drilling screw through the stay end bracket mounting hole and rear flange of the panel extrusion as shown below.

  • Page 23: Fly The Ceiling Assembly

    Ceiling Installation (continued) Fly The Ceiling Assembly WARNING WARNING Only qualified personnel who are Make sure that all rigging and rigging hardware familiar with rigging systems should is capable of lifting the ceiling panel component set up the rigging, add weights to calculated weight plus a reasonable margin of safety.

  • Page 24: Level The Ceiling Assembly

    Ceiling Installation (continued) Level the Ceiling Assembly 1. Position the ceiling panel row 4' to 5' (1219 to 1524 mm) from the floor surface. 2. Use a box level and check the length of the ceiling panel row and make sure that it is straight and level. a. Adjust turnbuckles to correct any non-straight or out-of-level conditions. b.

  • Page 25: Set The Ceiling Stay Performance Angle

    Ceiling Installation (continued) Set the Ceiling Stay Performance Angle Refer to the installation drawings when setting the ceiling stay performance angle. 1. Rotate the ceiling panel row into the storage (vertical) position. 2. Use a pair of 7/16" combination wrenches to loosen (finger tight) all of the hex head screws (four) and lock nuts on the latch receiver assembly. 3.
  • Page 26 Ceiling Installation (continued) Set the Ceiling Stay Performance Angle (continued) 4. Rotate the ceiling panel row slightly past the performance angle (perhaps 5 to 10 degrees). Ceiling panel rows are heavier on the upstage side. 5. Slide the ceiling stay receiver toward the ceiling stay latch until the receiver engages the ceiling stay latch. 6.

  • Page 27: Install The Ceiling Catch

    Ceiling Installation (continued) Install the Ceiling Catch Refer to the installation drawings for the ceiling catch location. 1. Remove a ceiling catch assembly from the shipping container. 2. Remove the two lock nuts from the u-bolt, remove the u-bolt from the ceiling catch pivot plate, and set the u-bolt and lock nuts aside.

  • Page 28: Light Fixture Installation

    ™ STOP If installing other light fixtures, contact Wenger. Inspection Before installing, inspect the light fixtures for any signs of damage. If any damages are present, immediately contact Wenger. Lieto LED Light Fixture Installation Install the light fixtures into the pre-cut ceiling panel holes. Refer to the installation drawings for locations. WARNING A licensed electrician must perform the electrical installation.

  • Page 29: Lieto Led Light Fixture Electrical Connection

    Light Fixture Installation (continued) Lieto LED Light Fixture Electrical Connection 1. Ensure the light fixture power source is compliant with local electrical codes. 2. Connect the PowerCON and RJ-45 or XLR DMX cables to the corresponding ports on the first light fixture control box. 3. Connect the PowerCON and RJ-45 or XLR DMX cable to the next light fixture in the row. Note: Ensure the supply voltage meets the Lieto LED light fixture requirements before securing connections. The Lieto light fixture requires non-dimmed mains power in the range of 100-240VAC 50/60Hz. 4. Power up the light fixture to ensure proper connections. Lieto Lieto Lieto CAUTION Light Light Light Fixture Fixture Fixture Do not connect or disconnect the LED First Light Fixture PowerCON connector under load.

  • Page 30: Light Fixture Configuration

    USB port next to the power/lock button. USB-A to USB-B Micro USB to USB Adapter 6. Select the Wenger app on the tablet home screen. 7. Once the app is open/running the diagnostic information window for the currently connected light fixture is displayed, view the information and select “ok”. 8. If a change to any of the fields is necessary, select the field, enter the new value, the select “set”.

  • Page 31: Configure The Dmxcat Connection

    Light Fixture Configuration (continued) Configure the DMXcat Connection ® USB to To configure the DMXcat device to communicate with the configuration tablet: Micro USB ® Cable 1. Gently insert the DMXCat’s 5-pin DMXcat XLR jack into the 5-Pin XLR panel XLR5F Connector mount plug with the protruding pins located on the light fixture control box. 2. Turn on the configuration tablet, once the home screen is displayed select the appstore icon. 3.

  • Page 32: Dmx Address Information

    Light Fixture Configuration (continued) DMX Address Information LED Power Settings Chart Wattage Power The Lieto White Fixture The Lieto Color Fixture Setting requires 1 DMX Channel requires 4 DMX Channels (0-255) Channel 1: Intensity (0-255) Channel 1: Red (0-255) Channel 2: Green (0-255) Channel 3: Blue (0-255) Channel 4: White (0-255) Troubleshooting...

  • Page 33: Photometrics

    Light Fixture Operation (continued) Photometrics...
  • Page 34 Light Fixture Operation (continued) Photometrics (continued)
  • Page 35 Light Fixture Operation (continued) Photometrics (continued)

  • Page 36: Schematics

    Schematics Lieto LED Light Fixture Electrical Schematic (Diva Acoustical Ceiling) ® CIRCUIT 4 LAMP 31 LAMP 32 LAMP 40 CIRCUIT 3 LAMP 21 LAMP 22 LAMP 30 CIRCUIT 2 LAMP 11 LAMP 12 LAMP 20 CIRCUIT 1 LAMP 1 LAMP 2...
