C
ONTeNTs
Before You Begin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Required Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Fastener Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Important User Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Manufacturer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Intended Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Routine Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Replacement Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Note: Please read and understand these Tablet Arm Assembly Instructions before attempting
installation, assembly, or use.
Note: Remove all items from the shipping containers and sort the components by type, size, etc.
Refer to the illustrations on the following pages. If you need additional information,
contact the Wenger Corporation using the information below.
©Wenger Corporation 2011
Wenger Corporation, 555 Park Drive, P.O. Box 448, Owatonna, Minnesota 55060-0448
Questions? Call.....USA: 1-800-4WENGER (493-6437) • Worldwide: 1-507-455-4100 • www.wengercorp.com
Printed in USA 03/11
Assembly Instructions
Tablet Arm
for Wenger Playright Chairs
Part #109M135-01
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Wenger Tablet Arm
Summary of Contents for Wenger Tablet Arm
- Page 1 Assembly ..............5 Note: Please read and understand these Tablet Arm Assembly Instructions before attempting installation, assembly, or use.
- Page 2 Remove all items from the shipping carton. ArrANTy The Wenger Tablet Arm is guaranteed free of defects in materials and workmanship for five full years. Our guarantee assures you of either a full refund or repair or replacement of the defective materials or workmanship without charge, at the discretion of our Customer Service Department.
- Page 3 Wenger Corporation. Wenger Corporation does not assume any responsibility for any errors that may appear in this manual. In no event will Wenger Corporation be liable for technical or editorial omissions made herein, nor for direct, indirect, special, incidental, or consequential damages resulting from the use or defect of this manual.
- Page 4 Spacer, Tablet Arm Bracket Nut, Lock, Flange, #10-24 Pivot Bracket, Tablet Arm Screw, SM, PH, ZP, 8 x 1/2 Cover, Pivot Bracket, Tablet Arm Screw, Tapping, LG, 5/16 x 3/4 Support Tube, Tablet Arm Capscrew, GD 2, ZP, 1-1/4-20 x 1-1/2 Bracket, Desk, Tablet Arm Nut, NY.
- Page 5 1. Mount the Tablet Arm Desk to the Support Tube as follows: a. Slide the Desk Bracket over the end of the Support Tube Support so that the slots engage the Stop Pins. Tube Be sure that the slots in the Desk Bracket are orientated to the inside of the chair (away from the longest side of 8 x ½...
- Page 6 ssembly ONTINUed 2. Place the chair upside down on a table or bench. Protect the chair by placing a pad or blanket on the work surface. 3. If the chair has bumpers installed, they must be removed. This can be done using a pliers to pull them out. Remove Bumpers 4.
- Page 7 ONTINUed 6. Slide the Support Tube of the Tablet Arm Desk Assembly into the 1” diameter hole of the Pivot Bracket. Tablet Arm Desk Assembly Weldment on the Support Tube 7. Assemble a 1¼-20 x 1½ Capscrew to the Rear of the Capscrew and ¼-20 Nut to the unattached...
- Page 8 Pivot Bracket Cover 12. Turn the chair back over and check the operation of the Tablet Arm Desk. a. Rotate the Tablet Arm Desk until the work surface is perpendicular to the floor. b. The Tablet Arm Assembly should be able to rotate 90 degrees upward and 90 degrees toward the back of the chair.
