Contents
Important User Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Manufacturer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Intended Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Safety Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Required Tools. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Fasteners. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Note: Please read and understand these instructions before assembling the parts.
Note: Remove all items from the shipping cartons and arrange them in a convenient location.
Refer to the illustrations on the following pages. If you need additional information,
contact the Wenger Corporation using the information below.
©Wenger Corporation 2019
Wenger Corporation, 555 Park Drive, P.O. Box 448, Owatonna, Minnesota 55060-0448
Questions? Call.....USA: (800) 4WENGER (493-6437) • Worldwide: +1-507-455-4100 • wengercorp.com
Tablet Arm Accessory
for Wenger Student and Musician Chairs
Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Determine Right Hand or Left Hand Set Up . . . . . . . . . . . . . 4
Tablet Arm Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Attach to Chair . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Printed in USA 2019-08
Assembly Instructions
Part #054K148-02
Advertisement
Table of Contents
Related Manuals for Wenger Tablet Arm Accessory
Summary of Contents for Wenger Tablet Arm Accessory
- Page 1 Refer to the illustrations on the following pages. If you need additional information, contact the Wenger Corporation using the information below. ©Wenger Corporation 2019 Printed in USA 2019-08 Part #054K148-02 Wenger Corporation, 555 Park Drive, P.O. Box 448, Owatonna, Minnesota 55060-0448 Questions? Call..USA: (800) 4WENGER (493-6437) • Worldwide: +1-507-455-4100 • wengercorp.com...
- Page 2 Wenger Corporation. Wenger Corporation does not assume any responsibility for any errors that may appear in these instructions. In no event will Wenger Corporation be liable for technical or editorial omissions made herein, nor for direct, indirect, special, incidental, or consequential damages resulting from the use or defect of these instructions.
- Page 3 Required Tools The following tools are required for assembly. · 3/8" wrench · 1/2" socket · Socket wrench · 7/16" wrench · 7/16" socket · Phillips head screwdriver Pliers (to remove chair bumpers) · Fasteners #8 x 1/2" #10-24 x 0.87" Pan Head Screw #10-24 Speaker Screw...
- Page 4 Assembly Determine Right Hand or Left Hand Set Up This tablet arm accessory can be mounted either the right or left side of to a STOP Wenger Student or Musician chair. Right hand or left hand set up must be determined before proceding.
- Page 5 Assembly (continued) Tablet Arm Assembly These instructions detail assembly for a right hand set up. For a left hand set up, the tablet arm illustrations would be reversed and installed on the opposite side of the chair. 1. From the top of the desk surface (12), thread two #10-24 x 0.87 speaker screws (1) through the pilot holes.
- Page 6 Assembly (continued) Attach to Chair 1. Place the chair upside down. Be sure to protect the seat surfaces from damage. If the chair has bumpers installed, they must be removed using a pliers. 2. Pre-cut the mounting holes by threading and then removing a 5/16"...
- Page 7 Assembly (continued) Attach to Chair (continued) 5. With the desk surface behind the back of the chair as shown, slide a bracket spacer (7) under the support tube to align with the holes on the opposite chair frame side. Orient the notch in the bracket spacer to the inside of the chair as shown. 6.
- Page 8 Operation To store the tablet arm accessory: 1. Rotate the desk surface up until it is perpendicular to the floor. 2. Rotate support tube upward towards the back of the chair. 3. Fold the desk surface inward behind the chair. CAUTION Never exceed 65 lb (29 kg) of weight on the tablet arm accessory.
