Module programming

Refer to "LED diagnostics and troubleshooting" for more information and for troubleshooting purposes.
If the Pre-Installation Module Programming was successful, skip Step 1 trough 2 and proceed with Step 3 (key2GO). Otherwise perform a
soft reset and reprogram your module.
Wait until the LED turns ON solid red.
1
Press the PTS button one time (1x) to turn the ignition ON.
1.
2
The LED flashes orange rapidly, turns green for 1 second, then flashes orange slowly.
Turn the ignition OFF and proceed with the next step.
2.
Remove the module from the vehicle, and reconnect it to your computer.
3
The website will automatically recognize that you are moving onto the second phase of the
programming sequence.
4
Click Submit Key2GO Request.
When the configuration is completed, reconnect the module.
1.
The LED flashes oranges rapidly.
5
2. Press the unlock button twice (2x) on the OEM remote.
The LED turns ON solid green for 3 seconds, then turns OFF.
You have successfully completed the module programming sequence.
12
403.NISS14 1.04 2022 Mitsubishi Outlander (Smart Key)
