PC/AT, PS/2 Universal
•
•
•
•
•
•
•
•
•
•
72
C d 39
These workstations support Caps Lock Sensing:
AT&T 6386SX
AT&T 6386WGS
Compaq (all models)
DEC 486
Dell Dimension 386
Dell Dimension 486
Dell Optiplex 486 PC
Gateway 2000 386 and 486
HP 486
IBM AT
Note: If your workstation does not support Caps Lock sensing, you can use the Caps
Lock configuration command ($+WL), as described in the Wedge Reader User's
Manual, to allow the reader to sense Caps Lock mode.
If the reader has Caps Lock Sensing enabled, the Caps Lock configuration command
($+WL) has no effect on the reader's ability to sense Caps Lock mode.
Keyboard Maps for Host Connections
If your PC is connected to a host computer (with terminal emulation software, for
example), you must use an alternate keyboard map.
Alternate keyboard maps are available for these workstations:
•
AT&T 6386SX
•
AT&T 6386WGS
•
Compaq
•
Compaq Prolinea
•
DEC 486
•
HP 486
•
HP Vectra ES
•
IBM AT
•
IBM ValuePoint
To select the alternate keyboard map, scan the appropriate "Host-Connected Keyboard
Map" bar code from the workstation configuration chart (see "Configuring the Reader"
later in this section). Scanning a "Host-Connected Keyboard Map" bar code maps your
keyboard to one of two maps.
•
IBM PS/1
•
IBM PS/2 (all models except PS/2 25)
•
IBM ValuePoint
•
NEC 286 and 386
•
Tandy 2500
•
Tandy 4016
•
Tandy 5000
•
Wang 240
•
Wang 280
•
Wang 380
•
NEC 286
•
NEC 386
•
PS/2 90 (122-key)
•
PS/2 95 (122-key)
•
PS/2 (101/102-key)
•
Tandy 2500
•
Tandy 4016
•
Tandy 5000
