Memorex/Telex Series

This section covers these workstations:
•
•
•
•
The individual Wedge Interface Guide corresponding to this section is part number
054303.
Cables
Connecting the reader to one of these workstations requires two cables: a keyboard
cable and a terminal cable. The interface kit contains both the keyboard and terminal
cables. If you need to order a replacement cable, use the part numbers listed below:
•
•
•
Power Supply
The reader does not require an external power supply to work with the workstation. Set
the PCB jumper to connect pins 1 and 2 on the reader's rear panel.
Configuring the Reader
Scan the appropriate label to configure the reader for your workstation. After the label is
scanned, the reader emits one low beep followed by four low beeps. The four low beeps
indicate the reader has successfully stored the configuration and is ready to read labels.
If the reader emits a different beep sequence, refer to the Wedge Reader User's Manual,
Section 2, for beeper identification.
To Set Workstation Configuration to

Memorex/Telex 1191

88-key Keyboard
Memorex/Telex 1191

Memorex/Telex 1192

Memorex/Telex 1196

Memorex/Telex 1197

Wedge interface kit (P/N 054302)
Keyboard cable (P/N 054301)
Terminal cable (P/N 054300)
C d 39
Memorex/Telex Series
•

Memorex/Telex 1471

•

Memorex/Telex 1472

•

Memorex/Telex 1476

•

Memorex/Telex 1477

•

Memorex/Telex 2296

Scan This Bar Code
*$+TA361*
*$+TA361*
63
