- Page 1 PM 23c |PM 43 |PM 43c UART+Industrial Interface Installation Instructions...
- Page 2 Intermec Technologies Corporation. Information and specifications contained in this document are subject to change without prior notice and do not represent a commitment on the part of Intermec Technologies Corporation. © 2012–2013 by Intermec Technologies Corporation. All rights reserved.
- Page 3 Install the UART+Industrial Interface Board Use these instructions to install the UART+Industrial interface board in Intermec PM23c, PM43, and PM43c printers. You will find these items in the shipping box: You will need the following tools to install the interface board: •...
- Page 4 3 Slide the latches counterclockwise into the open position. 4 Close the media cover and lift it off the hinges. 5 Put the media cover aside on a soft cloth to avoid scratches. PM23c, PM43, PM43c UART+Industrial Interface Installation Instructions...
- Page 5 2 Use a T20 Torx screwdriver to remove the two screws located on the outside of the electronics cover. 3 Remove the electronics cover, and put the cover aside on a soft cloth to avoid scratches. PM23c, PM43, PM43c UART+Industrial Interface Installation Instructions...
- Page 6 Torx screws removed in Step 1. 4 Use the T20 Torx screwdriver to secure the interface board assembly to the spacer screw with a Torx screw. PM23c, PM43, PM43c UART+Industrial Interface Installation Instructions...
- Page 7 UART+Industrial interface board. Note: You may need to use the dual option cable to connect to the main board depending on which slot you use for the UART+Industrial interface option board. PM23c, PM43, PM43c UART+Industrial Interface Installation Instructions...
- Page 8 8 Replace the electronics cover. 9 Replace the media cover. Worldwide Headquarters 6001 36th Avenue West Everett, Washington 98203 U.S.A. tel 425.348.2600 fax 425.355.9551 www.intermec.com © 2013 Intermec Technologies Corporation. All rights reserved. PM23c, PM43, PM43c UART+Industrial Interface Installation Instructions *931-101-002* P/N 931-101-002...
