Test Print –
Host Mode
Storing Label in
Printer
(Stored Mode only)
ERPLabel v. 2.0 for SAP R/3 – Installation & Operation Ed. 1
When the label has been completed, it is time for a test print, prior
to getting the label into the SAP R/3 system.
Print the label by using the Print Icon on the tool bar, the Menu File-
Print (short-cuts Ctrl-P or Function key F6).
When you are satisfied with the result, make sure the file is saved.
If the printer driver was set to Stored Mode, an additional dialogue
will be displayed as described below.
If you are going to use the Stored Mode, you will have to store the
current label layout in the printer.
This is done while printing the current label to the connected printer.
It works slightly different depending on the printer attached.
When Direct Protocol is used
You will be prompted for a layout name.
Enter a suitable name. Remember this name, as you will need to
enter it when saving the script for the SAPscript.
Note:
If you use a name of a current layout it will be overwritten.
When IPL is used
The layout will refer to the number selected in the driver settings
(in the Forms tab).
Note:
If the printer contains a layout on the current store position it will
be overwritten.
