CONNECT RAILS J, B AND H
Use the following illustrations and pictures as references for attaching the rails to the structure:
A
A
Step 4: Connect both J Rail sections between the back top corner of shaft A and the back top corner of shaft E.
Step 5: Connect both H Rail sections between the exit of the elevator and the front top corner of shaft A.
Step 6: Connect both B Rail sections between the front top corner of shaft E and the single side of the Rail Splitter.
Page 10
STEP 4
(J Rail)
STEP 5
(H Rail)
STEP 4
(J Rail)
Seaich Corporation, LLC. All rights reserved. www.seaich.com | Spacerails, LLC. www.spacerails.com
D
B
C
STEP 5
(H Rail)
E
STEP 6
(B Rail)
STEP 6
(B Rail)
E
