Summary of Contents for InFocus LP210
-
Page 1: Table Of Contents
Warranty Setting up the Projector Connecting an IBM-Compatible Computer Connecting a Macintosh Computer Connecting a Video Player Powering up the Projector and Adjusting the Image Turning Off the Projector Using the Projector Basic Image Adjustment Adjusting the Projector Using the Keypad Buttons... - Page 2 Appendix Specifications Accessories Portable and Laptop Activation Chart Using Video Mirroring with a PowerBook Computer Projected Image Size Index...
-
Page 3: Safety Summary
Do Not Look Into The Lens! Be extremely careful not to look into the projection lens when the projector is turned on. The bright light may harm your eyes. Be especially careful to keep children from looking into the lens. - Page 4 Follow the instruc- tions in this manual for lamp replacement carefully. Hot Surfaces Allow the projector to cool at least 45 minutes before replacing a lamp. When you open the lamp housing, be very careful not to touch the hot surfaces inside.
- Page 5 Openings in the projector case provide ventilation to protect it from overheating. Keep loose papers and other objects well away from the bottom, top and side grills. Do not place the projector on top of or close to a computer or other heat-producing equipment.
-
Page 6: Introduction
1024x768. If your computer’s screen res- olution is higher than 1024x768, reset it to a lower resolution before you connect the projector. Compatibility The projector is compatible with a wide variety of computers and video devices, including: IBM-compatible computers, including laptops, up to 1024x768 •... -
Page 7: Unpacking The Projector
Unpacking the Projector The projector comes with the items shown in Figure 1. Check to make sure all are included. Contact your In Focus dealer immedi- ately if anything is missing. If you are experienced in setting up presentation systems, use the LP 225 Quick Start card that was included in the shipping box. -
Page 8: Usage Guidelines
Do not look directly into the projection lens when the projector • is turned on. The bright light may harm your eyes. The top and bottom of the projector can be very hot to the • touch after use. Use extreme care or let it cool before lifting it. -
Page 9: Setting Up The Projector
• up the projector behind your screen. See “Rear Projection” on page 27 to reverse the image. If you are installing the projector on the ceiling, refer to the • LitePro 200 Series Ceiling Mount Installation Guide for more information. To turn the image upside down, see “Ceiling”... - Page 10 NOTE: Before you continue, make sure the projector and your equipment are turned off. If you’ r e connecting a computer, make sure the distance between it and the projector is 6 feet or less. composite s-video video IGURE Connector panel...
-
Page 11: Connecting An Ibm-Compatible Computer
Connecting the computer cable to an IBM-compatible computer Do you want to play your computer’s audio on the projector? 1 Plug either end of the audio cable into the audio connector on your computer. -
Page 12: Connecting A Macintosh Computer
CableWizard Lite computer cable into the connector on the projector. 4 If you want the projector display to be the same as the Power- Book’s screen display, turn on video mirroring (called SimulScan in newer PowerBooks). See “Using Video Mirror- ing with a PowerBook Computer”... -
Page 13: Connecting A Video Player
If you’re using S-video, plug the other end of the cable into • the “s-video” connector on the projector (Figure 7). Connecting the projector to a video player using the standard A/V cable (with composite audio/video cable video connector) IGURE... - Page 14 A/V cable IGURE Connecting the projector to a video player using an S-video cable and the audio con- nectors on the standard A/V cable 4 Plug the A/V cable’s white connector into the left “audio out” port on your video player. Plug the cable’s red connector into the right “audio out”...
-
Page 15: Powering Up The Projector And Adjusting The Image
Powering up the Projector and Adjusting the Image 1 Remove the lens cap. 2 Plug the power cord into the projector (Figure 8), then plug it into your electrical outlet. A surge-protected power strip is recommended if power surges are common in your area. -
Page 16: Turning Off The Projector
Turning Off the Projector If you want to turn off the projector for a short period of time, press the button on the keypad. This blanks the screen for standby fifteen minutes, but keeps the projector running. -
Page 17: Using The Projector
(page 11). 2 If the image doesn’t display completely, adjust the height of the projector (page 14) or center the image by adjusting its horizontal or vertical position (page 25). 3 If the image is out of focus, rotate the lens to focus it (page 13). - Page 18 IGURE Keystone adjustment knob The projector is equipped with an elevator foot on the underside of the projector and a leveling knob. IGURE Leveling knob leveling knob...
- Page 19 To raise the projector: 1 Raise the front of the projector off the table by lifting up on the handle (Figure 11). 2 Pull out the elevator foot (Figure 11). 3 If necessary, use the leveling knob (Figure 10) to adjust the angle of the projected image.
-
Page 20: Using The Keypad Buttons
Computer When you have more than one source (computer or video) con- nected to the projector, select between them by pressing the but- ton for the source you want. Press to display the computer image. - Page 21 Call your In Focus dealer for more information. Menu Press to open the on-screen menus. Press menu close the menus. When you close the menus, the projector saves any changes you made. For more information about the on- screen menus, see page 19. Mute Pressing the button silences the speaker.
- Page 22 Video When you have more than one source (computer or video) con- nected to the projector, select between them by pressing the but- ton for the source you want. Press to display the image from your video player.
-
Page 23: Using The Disk Mouse
Using the On-Screen Menus The projector has four on-screen menus that allow you to make image adjustments and change a variety of settings. To open the on-screen menus, press the pad. - Page 24 To change a menu setting, move the cursor to the setting you want to change, then use one of the two mouse buttons below the disk to make changes. The status bar at the top of the menu display indicates the source that is currently active.
-
Page 25: Display Menu Functions
Display Menu Functions Brightness Adjusting the brightness changes the intensity of the image. Press the left mouse button to darken the image. • Press the right mouse button to lighten the image. • Contrast The contrast controls the degree of difference between the lightest and darkest parts of the picture. - Page 26 Press the left mouse button to increase the amount of green in • the image. Press the right mouse button to increase the amount of red in • the image. Color setting adjusts a video image from black and white to Color fully saturated color.
-
Page 27: Audio Menu Functions
Audio Menu Functions Volume Press the left mouse button to decrease the volume. • Press the right mouse button to increase the volume. • Volume adjustments you make are saved for each source. Treble setting controls the higher frequencies of your audio Treble source. -
Page 28: Image Menu Functions
Auto Resize down. When is on, the projector makes the best fit of the Auto Resize image to the screen. If you turn image may be either cropped or too small for the screen. - Page 29 2 Press the left or right mouse buttons repeatedly until the image is sharp and free of streaks. Manual Tracking The tracking function adjusts the projector to match the video signal from your computer. The projector usually adjusts the tracking automatically when you connect your computer. How-...
-
Page 30: Controls Menu Functions
The input signals for SECAM, PAL-M, and PAL-N video cannot be automatically detected, therefore they must be chosen manually. If the projector is unable to detect the standard, the colors might not look right or the image might appear “torn.”... - Page 31 Click the button to toggle between the options. Auto Source Select This setting toggles between On and Off. When this feature is Off, the projector defaults to the source selected in Default Source. To display another source, you must manually select one by press- ing the...
-
Page 32: Maintenance & Troubleshooting
• scratch the lens. 2 Lightly wipe the cleaning cloth over the lens. 3 If you don’t intend to use the projector immediately, replace the lens cap. Removing and Replacing a Lens 1 Turn the focus ring counterclockwise until it reaches a stop. -
Page 33: Using The Optional Zoom Lens
Using the Optional Zoom Lens The zoom lens enlarges the projected image by 40% without moving the projector. (For more information about image size, see “Projected Image Size” on page 50.) Follow the previous instructions to install the zoom lens. -
Page 34: Replacing The Projection Lamp
See “Accessories” on page 43 for information. Follow these steps to replace the projection lamp: 1 Turn off the projector and unplug the power cord. 2 Wait 45 minutes to allow it to cool thoroughly. 3 Using a small, flat-blade screwdriver, remove the screw on the outside of the lamp door (Figure 22). - Page 35 10 Reposition the lamp cover. 11 Replace the screw and tighten it. 12 Turn the projector back on. 13 To reset the lamp hour counter in the Status bar, press and hold both Brightness buttons for 5-10 seconds. Verify that the counter was reset by pressing the menu button and viewing the counter.
-
Page 36: Replacing The Fuse
After you make sure that the condition that made the fuse blow no longer exists, follow these steps to replace the fuse: 1 Turn off the projector by pressing the “O” side of the power switch. 2 Unplug the power cord. - Page 37 5 Push the spare fuse into the holder until it is securely seated. 6 Place the fuse holder back in position (Figure 27). 7 Plug the power cord back in. 8 Press the “|” side of the power switch to turn the projector back on. IGURE...
-
Page 38: Using The Kensington Lock
The projector has a Kensington Security Standard connector for use with a Kensington MicroSaver Security System (Figure 28). Refer to the information that came with the Kensington System for instructions on how to use it to secure the projector. IGURE Installing the Kensington lock... -
Page 39: Troubleshooting
1 Check cable connections. Verify that all computer and power cables are properly connected. 2 Verify that all power is switched on. 3 Verify that the projector has not been switched off with the button on the keypad. standby 4 If the projector still doesn’t display an image, restart the com- puter. -
Page 40: Solutions To Common Problems
• tional AC electrical outlet. Make sure that the power cord is also properly connected to the projector. If the projector is plugged into a power strip, make sure the • power strip is turned on. Make sure you have removed the lens cap on the projection •... - Page 41 16 or “Video” on page 18. You might need to turn everything off and power up the equip- • ment again. Make sure you power up in this order: projector, computer monitor, computer. It is especially important that you follow this sequence for Macintosh computers.
- Page 42 Make sure that your computer has a compatible graphics • board. The projector is not compatible with CGA, EGA, or 1280x1024 graphics modes. Problem: Image is out of focus Make sure the lens is locked in place.
- Page 43 Replace the lamp as described in “Replacing the Pro- jection Lamp” on page 31. Problem: Lamp shuts off A minor power surge may cause the lamp to shut off. Turn the • projector off, wait at least 45 seconds, then turn it back on.
-
Page 44: Appendix
APPENDIX Specifications The LP 225 must be operated and stored within the temperature and humidity ranges specified. Temperature Operating 10 C to 40 C Non-operating -20 to 60 C Humidity Operating and non-oper. 10% to 95% relative humidity, non-condensing Dimensions 6.6 x 16.25 x 13.25 inches (16.8 x 41.3 x 33.7 cm) Weight 16 lbs. - Page 45 Video Module Input Input Impedance 5K ohm DC coupled Maximum Input Voltage Sensitivity 100 mV at 1 KHz for 88 dB SPL at 1 meter Connector Type RCA jack Audio Input Input Impedance 10K ohm nominal, AC coupled Maximum Input Voltage Sensitivity 100 mV at 1 KHz for 88 dB SPL at 1 meter Connector Type...
-
Page 46: Accessories
Audio Cable 6 ft (2m) Varifocal Lens Projection Lamp Module Lens Cap Audio/Video Cable Fuse — 6.3 amp Power Cords (one ships with projector, type depends on country) North American Power Cord Australian Power Cord UK Power Cord European Power Cord Danish Power Cord... - Page 47 Year Advantage Service Plan (1 year extension) Year Advantage Service Plan (2 year extension) SP-AP-LP2 CA-C077 CA-C092 CA-C119 SP-CW2 SP-CW2EXT SP-CW2EXTP HW-EXREM HW-EXRCVR HW-SMART HW-LSPRO CA-C131 HW-MEM-LSP HW-LP210-ZM SP-KENLOC call for part no. HW-HPSCRN SP-CEIL-LM2 SP-LTMT-PLT SP-LTMT-EXT SP-CWWALL SP-STND AS-LP2xx-12 AS-LP2xx-24...
-
Page 48: Portable And Laptop Activation Chart
Portable and Laptop Activation Chart Many laptop computers do not automatically turn on their exter- nal video port when a secondary display device such as a projec- tor is connected. Activation commands for some laptop computers are listed in the following table. (If your computer is not listed or the given command does not work, refer to the com- puter’s documentation for the appropriate command.) On some laptops, the activation function key is labeled with an icon, for... - Page 49 Key command to Computer activate port Compaq* ** Ctrl-Alt-< FN-F4 automatic mode/? (for setup option) Compuadd* ** automatic Alt-F for screen setup option Data General Ctrl-Alt-Command Data General 2 CRT/X at DOS prompt Walkabout Datavue Ctrl-Shift-M Dell** Ctrl-Alt-< Ctrl-Alt-F10 FN-F8 (CRT/LCD) FN-D FN-F12 Digital*...
- Page 50 Key command to Computer activate port IBM ThinkPad** reboot, enter setup menu FN-F7, select choice from setup menu FN-F1, select choice FN-F5, select choice PS/2 SC select choice (CRT, LCD, etc.) Kaypro boot up, monitor plugged Kris Tech FN-F8 Mac Portable no video port: not compatible Mac PowerBook 140, 145, 150,...
- Page 51 Key command to Computer activate port Packard Bell** FN-F2 Ctrl-Alt-< Panasonic FN-F2 Samsung* setup screen option Sanyo setup screen option Sharp dip switch to CRT Sun SPARC- Ctrl-Shift-M Dataview Tandy** Ctrl-Alt-Insert setup screen option Texas Instru- setup screen option ments* Top-Link* ** setup screen option FN-F6...
-
Page 52: Using Video Mirroring With A Powerbook Computer
If this happens, perform the following steps: 1 Turn off video mirroring. 2 Open the Monitors control panel. 3 Move the white menu bar to Monitor 2 to set the projector as the primary monitor. 4 Restart the PowerBook. -
Page 53: Projected Image Size
Projected Image Size Use the chart below and the tables on the next page to help you determine projected image sizes for the varifocal and zoom lenses. IGURE Projected image size for LP 200 series zoom and varifocal lenses... - Page 54 Table 1: Image Size, Width and Height for Varifocal Lens and Zoom Lens at Minimum Focusing Distance Distance to Diagonal Screen (feet) (inches) Table 2: Image Size, Width and Height for Zoom Lens at Maximum Focusing* Distance Distance to Diagonal Screen (feet) (inches) * The focusing distance of the zoom lens is from 4 feet to infinity.
-
Page 55: Index
16 color 22 contrast 21 Menu Position 22 tint 21 treble 23 volume 18, 23 adjusting the height of the projector 14 altitude limits 41 annotating 17 assistance. See Technical Support Audio menu 23 Audio menu options Bass 23... - Page 56 Help button 17 hot surfaces iv IBM-compatible computers compatibility 1 connecting 7 icons on projector labels iii on the projector 6, 9 image adjusting 11, 13 centering 13 colors don’t match computer’s 40 focusing 13 fuzzy lines 13, 25 has lines or spots 39...
- Page 57 Auto Image 24 Auto Resize 24 Horiz. Position 25 Manual Sync 24 Manual Tracking 25 Vert. Position 25 Kensington lock 35, 44 labels on projector iii lamp ordering 43 overheating iv replacing 31 safety iii–iv turns off unexpectedly 40 lamp hour counter 20...
- Page 58 37 tint, adjusting 21, 22 treble, adjusting 23 turning off projector 12 sound 17 turning on the projector 11 vertical lines displayed 25, 39 Video button 18 video mirroring on a PowerBook 8, 49 video standards 26 volume...
