Options; Cs-T81 Cloning Software (Option) - Icom IC-T81A Instruction Manual

D Battery packs
BATTERY VOLTAGE
CAPACITY
PACK
Battery case for R6(AA)
BP-197
× 3 alkaline or Ni-Cd cells
BP-198 700 mAh
4.8 V
BP-199 700 mAh
6.0 V
BP-200 680 mAh
9.6 V
* Operating periods are calculated under the following conditions:
Tx : Rx : standby=1 : 1 : 8;
Longer operating times are when operating on the 1200 MHz band.
D Chargers and cables
BC-110A/C/D/V WALL CHARGER
Regularly charge battery packs attached to the transceiver in 15 hrs.
BC-119 DESKTOP CHARGER +
AD-88 TERMINAL PC BOARD FOR CHARGER +
AD-87 BATTERY PACK ADAPTER +
Rapidly charge battery packs in 1 to 1.5 hrs. depending on the battery
pack. An AC adapter is packed with the BC-119 (except for the UK
version). The AD-87 must be used with the BC-119 for charging the
battery pack. The CP-17L or OPC-515L can be used instead of the
supplied AC adapter.
CP-12L CIGARETTE LIGHTER CABLE WITH NOISE FILTER
For operation and charging via a 12 V cigarette lighter socket.
OPC-254L DC POWER CABLE
For operation and charging via an external power supply.
OUTPUT OPERATING
POWER PERIOD*
0.8 W 10/14 hr
1.2 W 6/8.5 hr
2.0 W 4/8 hr
4.5 W 4/7 hr

OPTIONS

D Speaker-microphones
HM-46
HM-75A
Remote control
capability (see p. 27)
D Others
CS-T81 CLONING SOFTWARE
Allows you to clone the memory contents of an IC-T81 transceiver
between transceivers or to a PC for editing.
LC-148 CARRYING CASE
SP-13 EARPHONE
Provides clear receive audio in noisy environments.
13
HM-54
HS-85
• PTT switch
• VOX
• One-touch PTT for
hands-free operation
33
