TKS TKP TKM
Multi-Function Paddle Wheel Flow Meter
9.3 TKS - NPN (Flow Rate + Relay + Pulse) Diagram
Brown
1
TKS
Black
4
Flow
Meter
Grey
5
Output
Circuit
White
6
3 Blue
Black Wire is a Unit Volume NPN Pulse Output-1 Pulse for every Gallon
TKP - Yellow & Grey wires with RS - 485 Option Only
Current output (4 - 20mA) : 120
Voltage output (0 - 5V) : 10K
TKM Series (0-5VDC) Optional 4-20mA is Standard

10. Installation Positions

10x
CORRECT
10x
CORRECT
CORRECT
10x
for more information visit www.iconprocon.com
ROTATOR SERIES MANUAL
+V
Load
NO
1 AMP
COM
0V
max.
min.
3x
3x
3x
Brown 10 - 30 VDC (+)
Blue 0V (-)
Flow Rate Pulse
Black
Output (NPN)
INCORRECT
INCORRECT
INCORRECT
© Icon Process Controls Ltd. All Rights Reserved
White COM
Grey NO
1 Amp
