- Page 1 HDMI over IP Extender Series User Manual Model : HE03L-4K 4K HDMI CAT5e/6 Extender CAT5e 120M/CAT6 140M Smart Cabling & Transmission Corp. V1.0_1905301...
-
Page 2: Installation View
User Manual HE03L-4K Introduction HUE03-4K features the latest video interfaces, HDMI/ DisplayPort/USB-C, supporting up to 4K resolution, which provides user BYOD (Bring Your Own Device) presentations and collaborative meetings with a complete panel for smartphones, laptops & tablets. With the compatible HDMI receiver, HE03R-4K & HE03LR-4K, the solution suits any size of meeting rooms from small to the large scales. -
Page 3: Panel View
User Manual HE03L-4K Panel view HE03T-4K HE03LR-4K LED Indication Instruction Position Color Instruction Front Panel Green Power on/off Front Panel Blue TX/RX Linked RJ45 Green CAT5e Linked RJ45 Yellow Data Transmission Button Define HE03LR-4K Button Function Short press Display MAC、IP Long press 2 seconds Copy receiver monitor EDID to transmitter. -
Page 4: Troubleshooting
User Manual HE03L-4K RJ45 Pinout (PIN TIA/EIA-568B) (PIN TIA/EIA-568B) Wire Color Orange-white Orange Green-white Blue Blue-white Green Brown-white Brown Cable Link cable recommend use high quality CAT5e, CAT6 UTP/STP/FTP cable. The max working distance is 140M Poor quality cable or network connection or improper construction will cause unstable (Max) over CAT6. -
Page 5: Specification
User Manual HE03L-4K Specification ITEM NO. HE03T-4K HE03LR-4K Support Compliance HDCP 1.4 Max. Video Resolution 4K@30Hz 4:4:4, 1920 x 1200@120Hz Max. Transmission Distance 120M over CAT5e, 140M over CAT6 cable Audio Format 7.1 LPCM 192KHz Ports & Interfaces Video Input...
