- Page 1 HDMI over IP Extender Series User Manual Model : HE03L-4K 4K HDMI CAT5e/6 Extender CAT5e 120M/CAT6 140M Smart Cabling & Transmission Corp. V1.0...
- Page 2 Introduction HE03L-4K is a 4K HDMI extender that uses a cost-effective Ethernet cable to send an HDMI signal for up to 140M. Its chainable RX allows the extender to split an HDMI signal into up to 250 ones and display the signals at the same time.
- Page 3 User Manual HE03L-4K LED Indication LED Color Description Power GREEN ON/ OFF Power on/off LINK BLUE ON/ OFF TX/RX Linked RJ45 GREEN ON Linked RJ45 YELLOW ON Data Transmission EDID Configuration Button Description Press Display MAC, IP address Long press for 2 seconds Copy EDID from receiver to transmitter end.
- Page 4 User Manual HE03L-4K Specification ITEM NO. HE03T-4K HE03LR-4K Support Compliance HDCP 1.4 Max. Video Resolution 4K@30Hz 4:4:4, 1920 x 1200@120Hz Max. Transmission Distance 120M over CAT5e, 140M over CAT6 cable Audio Format 7.1 LPCM 192KHz Ports & Interfaces Video Input...
