- Page 1 IP/ PoE Extender User Manual Model : IP09CP PoE over Coaxial Extender Smart Cabling & Transmission Corp. V1.0 V1.0...
-
Page 2: Installation View
IP09CP Introduction IP09CP is a point-to-point PoE (Power over Ethernet) extender that can use single coaxial cable to extend TCP/IP signal and huge amount of power for a remote PoE device, such as speed dome camera, Dante PoE speaker, smart LED…etc., with no external power required. It’s a perfect solution for CCTV system, large-scale audio environment, smart building and factory.. -
Page 3: Panel Review
User Manual IP09CP Panel Review Interface Function Power Jack To connect with a DC48 ~ 56V adapter Power LED Indication To indicate the power status (Refer to Description 1) □ 1 Status : Port 1 mode indication (Refer to Description 3) Status Indication □... -
Page 4: Dip Switch Setting
User Manual IP09CP Status Indication □ □ Port Mode Status: LED Color Description Blue On Long Distance Blue Off Unlinked/ Ethernet Blinking 100Base-T1 RJ45 Pinout Data 1. Orange-white TX+ (DATA1+) PoE+ (Data Pair) 2. Orange TX- (DATA1-) PoE+ (Data Pair) 3. - Page 5 User Manual IP09CP Advanced Mode Please refer to the chart below to manually set up the Link Speed, and Modes Function ↑ OFF ↓ ON Link Speed 10Mbps 100Mbps Ethernet Disable Enable 100BASE-T1 Disable Enable Long Distance Disable Enable Auto-Negotiation Priority...
- Page 6 User Manual IP09CP Applying RG6U coaxial cable and power from 56V Power Adapter Input Power Distance Output Power 110W (56V/1.96A) 100M 100W (56V/1.79A) 200M 86W (56V/1.54A) 300M 88W (56V/1.59A) 400M 61W (56V/1.09A) 500M 47W (56V/0.84A) 600M 39W (56V/0.69A) 700M 37W (56V/0.67A) 800M 27W (56V/0.48A)
- Page 7 User Manual IP09CP Applying RG59 coaxial cable and power from 48V Power Adapter Input Power Distance Output Power 96W (48V/2.00A) 100M 65W (48V/x1.37A) 200M 39W (48V/0.81A) 300M 28W (48V/0.58A) 400M 21W (48V/0.44A) 500M 16W (48V/0.33A) 600M 14W (48V/0.29A) 700M 12W (48V/0.26A) 800M Applying RG6U coaxial cable and power from 802.3at PoE Switch (Zyxel GS1900-8HP)
-
Page 8: Jumper Settings
User Manual IP09CP Jumper Settings adjust the jumpers. We strongly recommend those who have advanced engineering skills to Improper adjustment may make the devices damaged. Any changes should start after turning off the power. IP09PT Jumper Settings: Position Function Setting Description Jumper cap on pin 1 &... - Page 9 User Manual IP09CP IP09PR Jumper Settings Position Function Setting Description Jumper cap on pin 1 & 2 PoE power ON (Default) Operation Mode Jumper cap on pin 2 & 3 PoE power OFF Jumper cap on pin 1 & 2 Support 802.3bt 90W (Default)
-
Page 10: Package Includes
User Manual IP09CP Package Includes Item Quantity IP09CPT IP09CPR Screw Screw Plug... -
Page 11: Specification
User Manual IP09CP Specification: ITEM IP09CPR IP09CPT Support IEEE 802.3 10BASE-T Ethernet IEEE 802.3u 100BASE-TX Fast IEEE 802.3 10BASE-T Ethernet Ethernet IEEE 802.3u 100BASE-TX Fast IEEE 802.3bw 100BASE-T1 Ethernet Ethernet IEEE 802.3bw 100BASE-T1 IEEE 802.3 N-Way Ethernet Auto-Negotiation IEEE 802.3 N-Way IEEE 802.3x Full Duplex...
