3. INSTALLATION METHOD

1. Wired remote controller structural dimensions

120mm

2. Remove the upper part of wired controller

• Insert a slot screwdriver into

the slots in the lower part of

the wired controller (2 places),

and remove the upper part of

the wire controller. (Fig.3-2)

LOKA HAHB remote control

20mm

Fig. 3-1

Buckling position

Straight head

screwdriver

Installation and user manual

46mm

60mm

Back cover

Front cover

Fig. 3-2
