Installation Accessory - Rotenso Control Series Installation And User Manual

• The specified cables shall be applied in the wiring. No external force may be applied
to the terminal. Otherwise, wire cut and heating may occur and result in fire.

2. INSTALLATION ACCESSORY

Select the installation location
Don't install at the place where cover with heavy oil, vapor or sulfureted gas, otherwise,
this product would be deformed that would lead to system malfunction.
Preparation before installation
1. Please CONFIRM that all the following parts you have been supply:
No.
1 Wire controller
2 Installation and owner's manual
3 Screws
4 Wall plugs
5 Screws
6 Plastic screw bars
7 Battery
8 The connective wires group
9 Screw
Name
LOKA HAHB remote control
NOTE
Qty.
1
1
3 M3.9X25 (For Mounting on the Wall)
3 For Mounting on the Wall
2 M4X25 (For Mounting on switch box)
2 For fixing on switch box
1
1 Optional
M4X8 (For Mounting the connective wire
1
group)
Installation and user manual
Remarks
-
-
-
EN
53
