2. Prepare the following assemblies on the site.
No.
1 Switch box
Wiring Tube (Insulating Sleeve and
2
Tightening Screw)
Precaution of installingthe wire controller
1. This manual provides the installation method of wired controller. Please refer to the
wiring diagram of this installation manual to connect the wire controller with indoor
unit.
2. The wired controller works in low voltage loop circuit. Forbid to directly contact the
cable of high voltage above,like 115V, 220V,380V, and don't wire this kind of wire in
the said loop; wiring clearance between configured tubes should be at the range of
300~500mm or above.
3. The Shielded wire of the wired controller must be grounded firmly.
4. Upon finish the wire controller connection, do not employed tramegger to detect the
insulation.
54
Installation and user manual
Name Qty.
1
1
Remarks
-
-
