Cabling and Specifications

Attach the line card cable-management bracket to the line card as follows:
Step 2
a.
b.
c.
For multiport line card cable-management brackets, carefully wrap the cables with the supplied Velcro
Step 3
strap. (See
For single-port line card cable-management brackets, carefully press the interface cable onto the cable
clip. (See
Cabling and Specifications
The following sections provide specifications for the ATM line card:
ATM Line Card Power Budget and Signal Specifications
The 4-port ISE ATM line card uses both single-mode and multimode fiber-optic cable. Signals can travel
farther through single-mode fiber than through multimode fiber. The maximum distance for installations
is determined by the amount of light loss in the fiber path. If your environment requires the light to travel
close to the typical maximum distances, you should use an optical time domain reflectometer (OTDR)
to measure the power loss.
The following sections describe the power budget and signal specifications for the optics used in each
ATM line card:
1-port OC-12c/STM-4c ATM Line Card Power Specifications
The 1-port OC-12c/STM-4c ATM line card provides the Cisco 12000 series router with a single
622-Mbps ATM interface.
a given case depends on the quality of the fiber attached to the transceiver.
ATM Line Card Installation and Configuration
22
Position the cable-management bracket over the front of the line card faceplate.
Insert and tighten the captive screw(s) to secure the bracket to the line card.
Starting with the bottom port on the line card, connect each interface cable to the intended port.
Figure
13.)
Figure
14.) Avoid any kinks or sharp bends in the cable.
ATM Line Card Power Budget and Signal Specifications, page 22
Fiber-Optic Network Interface Cables, page 24
1-port OC-12c/STM-4c ATM Line Card Power Specifications, page 22
4-port OC-3c/STM-1 ATM Line Card Power Specifications, page 23
4-port OC-12c/STM-4c ATM Line Card Power Specifications, page 23
8-port OC-3c/STM-1 ATM Line Card Power Specifications, page 23
4-port OC-12c/STM-4c ISE ATM Line Card Power Specifications, page 24
4-port OC-3c/STM-1 ISE ATM Line Card Power Specifications, page 24
Table 4
lists the power ratings and distances of the interface. The distance in
OL-13004-01
