Configuring Gigabit Ethernet Enhanced
High-Speed WAN Interface Cards
First Published: March 15, 2011
This document describes how to configure the Cisco Gigabit Ethernet enhanced high-speed WAN
interface card (EHWIC). The EHWIC 1 GE-SFP-CU can be installed on the Cisco Integrated Services
Routers Generation 2 (ISR G2) family platforms and has a dual-purpose uplink (DPU) that can run in
small-form-factor pluggable (SFP) or copper mode. It supports the following features:
•
Digital Optical Monitoring (DOM)
•
Support for T1/E1 and T3/E3 SFPs
•
Support for the Ethernet passive optical network (EPON) SFP
EHWIC 1 GE-SFP-CU is the SKU for the single port EHWIC.
For a list of SFPs supported on the EHWIC 1 GE-SFP-CU, see Connecting Gigabit Ethernet High-Speed
WAN Interface Cards document at the following URL:
http://www.cisco.com/en/US/docs/routers/access/interfaces/ic/hardware/installation/guide/EHWIC_1_
GE_SFP_CU.html.
Finding Feature Information in This Module
Your Cisco IOS software release may not support all of the features documented in this module.
Finding Support Information for Platforms and Cisco IOS Software Images
Use Cisco Feature Navigator to find information about platform support and Cisco IOS software image
support. Access Cisco Feature Navigator at
Cisco.com. If you do not have an account or have forgotten your username or password, click Cancel at
the login dialog box and follow the instructions that appear.
Americas Headquarters:
Cisco Systems, Inc., 170 West Tasman Drive, San Jose, CA 95134-1706 USA
http://www.cisco.com/go/fn.
You must have an account on

Advertisement

loading

Related Manuals for Cisco EHWIC 1 GE-SFP-CU

Summary of Contents for Cisco EHWIC 1 GE-SFP-CU

  • Page 1 Access Cisco Feature Navigator at http://www.cisco.com/go/fn. You must have an account on Cisco.com. If you do not have an account or have forgotten your username or password, click Cancel at the login dialog box and follow the instructions that appear. Americas Headquarters:...
  • Page 2 Prerequisites for the EHWIC 1 GE-SFP-CU This section lists the prerequisites for configuring the EHWIC 1 GE-SFP-CU. Ensure that you have the appropriate Cisco access router to serve as the host router. The following • Cisco access routers support EHWIC 1 GE-SFP-CU.
  • Page 3 EHWIC 1GE SFP CU provides maximum 800 Mbps unidirectional and 1600 Mbps bidirectional Ethernet throughput, but the actual throughput is limited by the platform. The SFP slot supports Cisco certified copper or optical SFPs. For a list of supported SFPs, see Connecting Gigabit Ethernet High-Speed WAN Interface Cards.
  • Page 4 1 blink before pause—10 Mbps link speed. 2 blinks before pause—100 Mbps link speed. 3 blinks before pause—1000 Mbps link speed. Configuring the EHWIC 1 GE-SFP-CU This section describes how to configure your EHWIC 1 GE-SFP-CU. SUMMARY STEPS enable configure terminal...
  • Page 5 Use the loopback command in interface configuration mode to configure loopback. The EHWIC 1 GE-SFP-CU supports MAC layer loopback and driver type loopback. The MAC loopback is used to detect MAC failure. The driver loopback is used to detect transceiver failure. Use the show interface to see the loopback mode and check if the hardware is functional.
  • Page 6 Show Controller Output, page 9 • Show Interface Output, page 12 • EHWIC 1 GE-SFP-CU Running Configuration The following example shows the running configuration with the EHWIC 1 GE-SFP-CU on a Cisco 3945 ISR. Router# sh run Building configuration... Current configuration : 2132 bytes ! Last configuration change at 01:33:00 PDT Tue Sep 28 2010 version 15.1...
  • Page 7 Configuration Examples for EHWIC 1 GE-SFP-CU redundancy interface GigabitEthernet0/0 no ip address duplex auto speed auto interface GigabitEthernet0/1 no ip address shutdown duplex auto speed auto interface GigabitEthernet0/2 no ip address duplex auto speed auto interface GigabitEthernet0/3/0 interface GigabitEthernet0/3/1 interface GigabitEthernet0/3/2...
  • Page 8 Configuration Examples for EHWIC 1 GE-SFP-CU ip forward-protocol nd no ip http server no ip http secure-server logging esm config control-plane line con 0 exec-timeout 0 0 line aux 0 line 67 no activation-character no exec transport preferred none transport input all...
  • Page 9 Configuration Examples for EHWIC 1 GE-SFP-CU PID: PVDM2-64 , VID: V01 , SN: FOC1052368L NAME: "SM-ES3-24-P: EtherSwitch SM L3 + PoE + 23 10/100 + 1 10/100/1000 on Slot 1", DESCR: "SM-ES3-24-P: EtherSwitch SM L3 + PoE + 23 10/100 + 1 10/100/1000"...
  • Page 10 Configuration Examples for EHWIC 1 GE-SFP-CU date_code 08090349 (yymmddvv, v=vendor specific) cc_ext 0xC5 Digital Diag Type 0x00 (Not available) PHY Registers ------------- Register 0x00: 1000 01CD 0362 5D12 0000 0000 0004 2001 Register 0x08: 0000 0000 0000 xxxx xxxx xxxx xxxx C000...
  • Page 11 Configuration Examples for EHWIC 1 GE-SFP-CU Fragment Frames Received : 0 In-Range Length Errors : 0 Alignment Errors Received : 0 Symbol Errors Received : 0 Internal MAC Errors : 0 EHWIC-1GE-SFP Mac Tx Statistics: ============================================= Bytes Transmitted : 2997...
  • Page 12 Configuration Examples for EHWIC 1 GE-SFP-CU Management Interrupt Enable (0x6000): Hwic Int Frame Mgmt Int 0x06 IRQ2 Int 0 IRQ1 Int 0 Graceful Stop Tx Int 0 Network Interrupt Enable (0x3C00): Rx Frame Drop Int 1 Generic Frame Tx Int 1...
  • Page 13 Third-party SFPs are manufactured by companies that are not on the Cisco-approved Vendor List (AVL). Currently, Cisco ISR G2 routers support only Cisco-approved SFPs. From Release 15.3(2)T, Cisco ISR G2 routers recognize third-party SFPs. Cisco does not provide any kind of support for the third-party SFPs because they are not validated by Note Cisco.
  • Page 14 Cisco 2921 Integrated Services Router • Cisco 2951 Integrated Services Router • Cisco 3900 Integrated Services Router • Cisco 3900E Series Integrated Services Routers • Cisco 892-F Gigabit Ethernet Security Router • Cisco 898-EA Gigabit Ethernet Security Router • EHWIC-1GE-SFP •...

  • Page 15: Additional References

    Example: Router(config-if)# exit Router(config)# Examples This example shows how to configure a third-party SFP on a Cisco ISR G2 Series Router: Router# configure terminal Router(config-if)# service unsupported-transceiver Router(config)# interface ethernet 0/3/0 Router(config-if)# media-type sfp Router(config-if)# speed 100...
