Control (193/260); Removal; Installation - Danfoss D1 Series Service Manual

Service Manual
D1 High Power Open Circuit Pumps Size 65/130/145/193/260
Minor repairs

Control (193/260)

© Danfoss | July 2019

Removal

1. Remove the control from the endcap by removing the mounting bolts (See Control seal type and
mounting bolts). If the control has the TC/DC feedback link (D640), ensure that it does not stay in the
hole of the bias piston in the endcap, remove it and place it with the control.
2. Remove and discard the seals (See Control seal type and mounting bolts) .

Installation

1. Install new seals (See table Control seal type and mounting bolts). Proper gasket alignment is dictated
by alignment pins in the control housing. For O-rings, lightly lubricate them prior to assembly.
2. If the control uses a TC/DC feedback link, make sure that it is set in the bias piston hole, then install
the control housing assembly onto the endcap using the mounting bolts.
Control seal type and mounting bolts
Control
NPNN (130-260)
NPSN (130-260)
TPSN (193/260)
TPSN (130/145)
NNES (130-260)
TPE2/TPE5 (130-260)
NPNR (130-260)
Torque requirements
Bolt
D175
D170
D180
Seal type Mounting bolts
Gasket (D145) 5 short bolts (D175)
Gasket (D145) 5 short bolts (D175)
Gasket (D145) 5 short bolts (D175)
1 O-ring (D140) & 3 O- 5 short bolts (D175)
rings (D150)
Gasket (D145) 5 short bolts (D175)
Gasket (D145) 3 long bolts (D170) & 2
short bolts (D180)
Gasket (D145) 5 short bolts (D175)
Torque
22.5-27.5 N·m [199-243 lbf·in]
22.5-27.5 N·m [199-243 lbf·in]
22.5-27.5 N·m [199-243 lbf·in]
TC/DC feedback link
No
No
Yes
Yes
Yes
Yes
No
L1527453 | AX00000292en-CN0201 | 49
