Water Connection

HOT
WATER
CAUTION:
plumber must thoroughly flush debris from the water supply line before connecting
it to the dishwasher. Damage caused by improper installation is not covered by the
limited warranty.
NOTE: All plumbing connections MUST BE POSITIONED to allow the machine to be
moved for service and cleaning.
BOOSTER
BOOSTER
kW
RISE °F
40
°
RISE
70
°
RISE
WATER HARDNESS OF 3 GRAINS/US GAL - 0.83 IMP GAL - 5.3mg/L
OR LESS.
THE DISHWASHER IS EQUIPPED WITH A 6 FT / 1.8 m FLEXIBLE FILL
HOSE WITH A 3/4" FNPT FITTING.
THE PRV SHIPPED INSIDE THE DISHWASHER MUST BE INSTALLED
IN THE INCOMING WATER LINE AFTER THE SERVICE SHUT-OFF VALVE.
THE PRV MUST BE ADJUSTED TO PROVIDE 20-22 PSI FLOWING
PRESSURE MEASURED AT THE DISHWASHER.
INSTALL A 1/2" OR LARGER SHUT-OFF VALVE IN THE WATER SUPPLY
LINE AS CLOSE TO THE DISHWASHER AS POSSIBLE FOR SERVICING.
Connect the plumbing in accordance with the specifications below.
MINIMUM 1/2" NPT OR LARGER HOT WATER SUPPLY LINE.
To prevent damage to the dishwasher supply valves, the installing
MINIMUM INCOMING
TEMPERATURE
140°F/ 60°C
4kW
110°F/ 43°C
6kW
MIMIMUM INCOMING
SUPPLY FLOWING PRESSURE
45 PSI/310 kPa
20-22 PSI 138-152 kPa
45 PSI/310 kPa 20-22 PSI 138-152 kPa
Continued on the next page.
Installation
MIMIMUM/MAXIMUM
OPERATING FLOWING PRESSURE
3
