MODEL CMA-180UC
PARTS MANUAL
Rev 1.14
C M A D I S H M A C H I N E S
1 2 7 0 0 K N O T T A V E N U E
GARDEN GROVE, CALIFORNIA 92841
8 0 0 - 8 5 4 - 6 4 1 7
F A X 7 1 4 - 8 9 5 - 2 1 4 1
wwwcmadishmachines.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CMA-180UC and is the answer not in the manual?

Questions and answers

Related Manuals for CMA Dishmachines CMA-180UC

Summary of Contents for CMA Dishmachines CMA-180UC

  • Page 1 MODEL CMA-180UC PARTS MANUAL Rev 1.14 C M A D I S H M A C H I N E S 1 2 7 0 0 K N O T T A V E N U E GARDEN GROVE, CALIFORNIA 92841...

  • Page 2: Table Of Contents

    1.4.6. Drain System Assembly... 12 1.4.7. Wash System ... 13 1.4.8. Rinse System ... 14 1.4.9. Pump System Assembly... 15 1.4.10. Heater Assembly ... 16 ABLE OF ONTENTS CMA-180UC ODEL ... 4 —I ... 5 NSTALLATION NSTRUCTIONS ... 7 wwwcmadishmachines.com...

  • Page 3: Parts Manual

    1/2” Water Solenoid Repair Kit – J/E 04103.00 L1X/L1-C Drain Valve 120V 00206.00 Pump Seal Kit 13417.89 Heater Thermostat 17523.60 High Limit Switch 200°F 00411.00 Microswitch 00738.15 3/4” Water Solenoid Valve Coil – J/E MODEL CMA-180UC PARTS MANUAL Rev. 1.14 Parts Manual DESCRIPTION Page...

  • Page 4: Optional Drain Pump Kit

    1.2. Optional Drain Pump Kit ITEM REQ’D 15503.00 Drain Motor Ultra Jet for CMA-180UC 00432.50 Twist Tie 15601.10 Black Drain Hose 1" ID X 3 1/2" 15601.50 Drain Hose 1" ID, 6 ft 15601.60 Robber Hose 90 Deg. MODEL CMA-180UC PARTS MANUAL Rev. 1.14...

  • Page 5: Pump

    Remove the terminal cover and connect the white and purple wires to the two white wires from the pump. Replace the cover. MODEL CMA-180UC PARTS MANUAL Rev. 1.14 Parts Manual NSTALLATION...
  • Page 6 Secure the drain gooseneck to the wash riser pipe with the hose clamp provided as shown in Route the drain hose to the drain and provide a 1-inch air gap at the drain. MODEL CMA-180UC PARTS MANUAL Rev. 1.14 Parts Manual Figure 3.

  • Page 7: Mechanical Drawings

    01310.60 Leg Adjusters for CMA-180UC 14506.50 Door Gasket for CMA-180UC 14506.45 Gasket Bracket for CMA-180UC 00940.50 10-32 x 3/8 Trusshead Screw MODEL CMA-180UC PARTS MANUAL Rev. 1.14 ITEM DESCRIPTION Parts Manual DESCRIPTION REQ’D 00941.00 10-32 x 5/8 Panhead Screw 03801.00 10-32 Lock Nut 00940.51...

  • Page 8: Door Assembly

    Door for CMA-180UC 04517.60 Door Support Rod Block 14570.00 Door Hinge R.H. for CMA-180UC 14570.50 Door Hinge L.H. for CMA-180UC 04919.00 Door Rod Screw Pin for CMA-180UC 04918.60 Door Support Rod Right 04919.50 Door Support Rod Left 00557.80 Door Magnet 00970.60 6-32 x 1/2”...

  • Page 9: Electrical Tray

    1.4.3. Electrical Tray ITEM REQ’D 14504.00 Electrical Tray for CMA-180UC 14408.80 Timer Assy 4 Cam 2 Min. CMA-180UC 15504.00 Motor Contactor, 2-Pole 20 Amp 15504.50 Heater Contactor, 2-Pole 35 Amp 15520.50 Power Block, 3-Position 00438.00 Snap Bushing, Universal 01001.00 6-32 x 1” Panhead Screw MODEL CMA-180UC PARTS MANUAL Rev.

  • Page 10: Control Panel

    15523.50 Rocker Switch Drain/Fill DPDT/Mom. 15524.00 Rocker Switch Power Maintained 13426.50 Ground Block 00438.00 Snap Bushing, Universal MODEL CMA-180UC PARTS MANUAL Rev. 1.14 Parts Manual ITEM DESCRIPTION REQ’D *Kit includes 2 of #03202.66 DESCRIPTION 01001.00 6-32 x 1” Panhead Screw 00965.00...

  • Page 11: Plumbing System Assembly

    1/2" Strainer Ball Valves 00214.60 1/4” Compression x 1/2” MIP FTG 00743.10 1/2" T,FxFxF 05007.60 Vacuum Breaker Line 03624.00 1/2” Vacuum Breaker – Watts MODEL CMA-180UC PARTS MANUAL Rev. 1.14 ITEM DESCRIPTION Parts Manual DESCRIPTION REQ’D 00739.50 Vacuum Breaker Cap, SS 03624.25 Vacuum Breaker Bonnet, Brass 03623.00...

  • Page 12: Drain System Assembly

    1.4.6. Drain System Assembly ITEM REQ’D 04103.00 L1X/L1-C Drain Valve 120V 03101.00 Hose Clamp #16-1” 15601.60 Hose 1” ID 7” Pump to Manifold MODEL CMA-180UC PARTS MANUAL Rev. 1.14 ITEM DESCRIPTION Parts Manual DESCRIPTION REQ’D 04106.00 1” 90° Barb x Barb Elbow 15601.10 Black Drain Hose 1"...

  • Page 13: Wash System

    1.4.7. Wash System ITEM REQ’D 00304.45 Wash Arm 00308.20 Wash Arm End Plug MODEL CMA-180UC PARTS MANUAL Rev. 1.14 ITEM DESCRIPTION Parts Manual DESCRIPTION REQ’D 04305.17 Red Silicon Gasket 1/16” Thick Page 13...

  • Page 14: Rinse System

    1.4.8. Rinse System ITEM REQ’D 00304.65 Rinse Arm CMA-180UC 13304.55 SS Final Rinse Spray Jet – HT MODEL CMA-180UC PARTS MANUAL Rev. 1.14 ITEM DESCRIPTION Parts Manual DESCRIPTION REQ’D 04305.17 Red Silicon Gasket 1/16” Thick 00308.17 Rinse Arm End Cap...

  • Page 15: Pump System Assembly

    Water Pump Motor for CMA-180UC 00921.00 3/8”-16 x 3/4” Hex Bolt 03224.00 Pump Base (Mount) 00206.00 Pump Seal Kit 03222.05 Impeller L-1M MODEL CMA-180UC PARTS MANUAL Rev. 1.14 ITEM DESCRIPTION Parts Manual DESCRIPTION REQ’D 04206.00 Pump Cover 00208.00 Slip Joint Nut Gasket 04204.00...

  • Page 16: Heater Assembly

    Heater 6kW for CMA-180UC 13417.89 Heater Thermostat 17523.60 High Limit Switch 200°F 15517.10 Heater Gasket 13805.00 5/16”-18 Nylon Insert Lock Nut MODEL CMA-180UC PARTS MANUAL Rev. 1.14 ITEM DESCRIPTION Parts Manual DESCRIPTION REQ’D 00926.00 5/16” SS Washer 40116.00 1/4” Compression x 1/4” MIP FTG 00965.00...
