Drain Connection
30
20
40
psi
10
50
0
60
Fig. 4
Do not void the limited warranty.
*18
IN.
OPTIMUM
3
*
FT. MAX OFF
FLOOR LEVEL
Fig. 3
Configuring the drain line.
DO NOT
REPOSITION
THE DRAIN HOSE
DO NOT ADD AN
EXTENSION TO
THE DRAIN HOSE
Installation
DRAIN MUST BE
VENTED TO PREVENT
SYPHONING
DRAIN HOSE
3/4 IN. MNPT
HOSE ADAPTER
1-1/2 IN. WYE
FITTING
5
