CMA Dishmachines UC65e M3 Installation & Operation Manual page 6

Receiving
1. Inspect the outside of the dishwasher carton for signs of damage.
2. Remove the carton and inspect the dishwasher for damage.
3. Check for any options or accessories that may have shipped with your
dishwasher.
4. Register by fax using the form at the front of this manual or online at:
https://cmadishmachines.com/warranty-registration/
CAUTION:
Be careful when lifting and moving the machine to avoid damage.
Placement
1. Compare the installation site utility connections with the dishwasher utility connections and
make sure they are the same.
2. Level the machine using the four leveling feet. Level side-to-side and front-to-back.
3. Plumbing connections must be made before the electrical installation begins.
4. The dishwasher can be installed as a free-standing unit or under a counter-top. The typical
counter-top height in most locations is 34" [86cm].
5. It is highly recommended that the underside of the counter-top be clad in metal.
6. Under counter installations should provide storage space for the dishwasher chemical
supply containers. Do not elevate the containers above the finished floor.
7. Chemical supply containers should be placed as close to the machine as possible.
8. The chemical tubing taped to the back of the machine must be repositioned before
permanently placing the machine.
9. Place the dishwasher in its permanent location.
10. Remove the lower front panel in preparation for
utility installations.
Do not elevate chemical containers
Fig. 1 -
Receiving/Placement/Installation Codes
L E V E L
30
20 40
psi
10 50
0 60
LEVEL ADJUSTMENT
Fig. 2 -
Level the machine.
