Removing the C200 CPU Board
Removing the C200 CPU Board
Figure 3 Removing the CPU Board (C200)
8
Perform the following steps to remove the C200 CPU board from the system
unit:
1 Remove the Main Tray Assembly.
2 Remove the two CPU board retaining screws, as shown in Figure 3.
3 Pull the two ejector handles at the same time, as shown in Figure 3.
4 Slide the CPU board out approximately one inch, then lift it straight up to re-
move it. Be sure to support the board under the heat sink or you will damage
the CPU board.
