Installing the C200/C240 to C360 CPU Upgrade
HP Part No. A4200-90051
E1298
Printed in USA

Advertisement

Table of Contents
loading

Related Manuals for HP Visualize c200

Summary of Contents for HP Visualize c200

  • Page 1 Installing the C200/C240 to C360 CPU Upgrade HP Part No. A4200-90051 E1298 Printed in USA...

  • Page 2: Printing History

    3. HP does not warrant that the operation of HP products will be uninterrupted or error free. If HP is unable, within a reasonable time, to repair or replace any product to a condition as warranted, customer will be entitled to a refund of the purchase price upon prompt return of the product.
  • Page 3 FOR CONSUMER TRANSACTIONS IN AUSTRALIA AND NEW ZEALAND: THE WARRANTY TERMS CON- TAINED IN THIS STATEMENT, EXCEPT TO THE EXTENT LAWFULLY PERMITTED, DO NOT EXCLUDE, RESTRICT OR MODIFY AND ARE IN ADDITION TO THE MANDATORY STATUTORY RIGHTS APPLICABLE TO THE SALE OF THIS PRODUCT TO YOU. This document contains proprietary information that is protected by copy- right.

  • Page 4: Installation Prerequisites

    Installation Prerequisites Before upgrading your Model C200/C240 to a Model C360, your current system must be running HP-UX 10.20 or greater with Additional Core Enhancements (ACE) 9806 for Workstations (June 1998) and IPR 9812. For optimal performance, use HP-UX compilers from August 1998 or later.
  • Page 5 C240 to a C360. 1 Prepare your workstation • Verify that you have the correct version of HP-UX. • Determine and WRITE DOWN the LAN ID of your system. You may need to re-enter it in the new system board.

  • Page 6: Preparing Your Workstation

    Before starting the upgrade, use the following procedure to prepare the workstation: 1 The workstation must be running HP-UX 10.20 or later with Additional Core En- hancements (ACE) 9806 and IPR 9812 to accommodate the C360 upgrade. Use the command uname -r to determine the revision of your operating system. It should report B.10.20.
  • Page 7 LAN ID. 3 Log out of your system and enter a command line session as follows: HP VUE: At the login window, select Options, then select No Windows. HP CDE: At the login window, select Option, then select 4 Power off your workstation by pressing the power button on the front panel.
  • Page 8 Preparing Your Workstation 9 Remove the floor stand from the system unit, as shown in Figure 1. Figure 1 Removing the Floor Stand 10 Lay the system unit on a flat surface, such as a table top. 11 Attach a static-grounding wrist strap to bare metal on the back of the system unit.
  • Page 9 Preparing Your Workstation CAUTION: The internal components of your workstation are susceptible to mechanical and electrostatic shock. To prevent such damage from occurring, observe the following precautions during the installation procedure: Stand on a static-free mat (if available). Wear a static-grounding wrist strap to ensure that any accumulated electrostatic charge discharges from your body to ground.

  • Page 10: Removing The Main Tray Assembly

    Removing the Main Tray Assembly Removing the Main Tray Assembly Once you have prepared the workstation, you need to remove the main tray from the system unit, as described in the following procedure: CAUTION: Do NOT attempt to remove the main tray assembly when the workstation is in a vertical orientation.
  • Page 11 Removing the C200/C240 CPU Board Perform the following steps to remove the C200/C240 CPU board from the sys- tem unit: 1 Remove the Main Tray Assembly. 2 Remove the two CPU board retaining screws, as shown in Figure 3. 3 Pull the two ejector handles at the same time, as shown in Figure 3. Figure 3 Removing the CPU Board (C200/C240) 4 Slide the CPU board out approximately one inch, then lift it straight up to re-...
  • Page 12 Installing the C360 CPU Board Installing the C360 CPU Board Perform the following steps to install the C360 CPU board into the system unit: 1 Be sure to support the board under the heat sink or you will damage the 2 Push the two ejector handles at the same time, as shown in Figure 4.
  • Page 13 Transfer Memory Modules From the Old CPU Board to the New CPU Board Transfer Memory Modules From the Old CPU Board to the New CPU Board 1 Place the old and the new CPU boards next to each other. 2 Locate the memory module connectors as shown in Figure 5. Memory Connectors Figure 5 Memory Module Location (C200/C240)

  • Page 14: Removing A Memory Module

    Transfer Memory Modules From the Old CPU Board to the New CPU Board 3 To remove a memory module, push the ejector tabs on each side of the module. Lift the memory module up and out of the connector. Figure 6 shows how to re- move a memory module.

  • Page 15: Installing A Memory Module

    4 To install a memory module, close the ejector tabs on each side of the memory connector and line the memory module up with the guides, as shown in Figure 7. Make sure that the notched end of the memory module is toward the white ejector tab as shown in Figure 7.
  • Page 16 Installing the Main Tray Assembly Installing the Main Tray Assembly Install the C360 main tray assembly, as described in the following proce- dure: 1 Align the main tray assembly with the chassis and slide it into place, as shown in Figure 8.
  • Page 17 Installing the Main Tray Assembly 5 Use a small flat blade screwdriver to gently pry the old model number label from the front of the system. Remove the backing from the new C360 model number label that came with the upgrade, and press it firmly into place as shown in Figure Model Number Label Figure 9 Installing the Model Number Label...
  • Page 18 Installing the Main Tray Assembly 6 Remove the backing from the C360 FCC Regulatory Label sticker and affix the sticker over the FCC Regulatory Label on the Pullout Card at the rear of the SPU. Figure 10 Install Regulatory Label...
  • Page 19 7 If you plan to use your system in a vertical position, install the floor stand, as shown in Figure 10. Figure 11 Installing the Floor Stand 8 Reconnect the power cord and any other cables and terminators that you discon- nected when you opened the workstation.
  • Page 20 Installing the Main Tray Assembly NOTE: There will be a one to two minute delay, while the self-tests complete, before any monitor activity occurs. Power saving monitors may switch to their power saving mode during this time This concludes the hardware upgrade. 10 Pack the old CPU board back in the antistatic bag and place it in the upgrade kit box and use the documentation provided to return the old parts to Hewlett-Pack- ard for credit.
  • Page 21 Installing the Main Tray Assembly Figure 12 System Rear Panel Connectors Power Optional Monitor LAN-AUI LAN-TP Serial 1 Serial 2 PS/2 Mouse PS/2 Keyboard Built in Monitor HP Parallel Single-Ended SCSI Ultra, Wide SCSI Audio Line Out Audio Line In Security Loop Pullout Card...
  • Page 22 Installing the Main Tray Assembly...
