Summary of Contents for Comeup Cub 3

  • Page 2: Safety Requirement

    WARNING: FAILURE TO READ AND FOLLOW THE SAFETY INSTRUCTIONS IN THIS OWNER’S MANUAL BEFORE INSTALLING OR USING YOUR ATV/UTV WINCH Thank you for purchasing a COMEUP Winch. This manual covers operation and COULD RESULT IN DAMAGE TO YOUR WINCH AND SERIOUS OR FATAL INJURY!! maintenance of the winch.

  • Page 3: Main Components

    II. Main Components Winch & Roller Fairlead/Hawse Fairlead Mounting 1. It is very important that the winch shall be mounted on a flat hard surface in order to make sure the motor, drum and gearbox housing are aligned correctly. 2. If a different mounting plate is used, the thickness shall be at least 5 mm (3/16”).

  • Page 4: Operation

    IV. Operation Remote Socket Mounting (Option) Cable In and Out 1. Determine the mounting location for the remote socket. 1). To determine “Cable Out“, Press to the “Out” position 2. Drill three holes on a plate and install. 2). To determine “Cable In“, Press to the “In” position 3).

  • Page 5: Maintenance Schedule

    Maintenance Schedule V. Maintenance Carry out all inspections below on schedule. All inspections are performed by Daily, Wire Rope/Synthetic Rope Replacement Monthly and Quarterly basis. Clean all connections because corrosion on electrical connections will reduce performance or may cause a short. Before installing a new wire rope/synthetic rope, wrap the end of the wire rope/synthetic rope with tape to prevent fraying.

  • Page 6: Troubleshooting

    VI. Trouble Shooting When the winch fails to operate after several attempts, or if there is any fault operation while winching, check followings. Symptom Possible Cause Remedy Cut circuit or loosing Check battery lead Weak battery or insufficient power Recharge or replace battery Damaged over-load protector Replace over-load protector Loose connection of wirings...
