  • Page 2 Compact Winch Thank you for purchasing a Winch. This manual covers operation and maintenance of the winch. All information in this publication is based on the latest production information available at the time of printing. General Safety Precautions Winch is designed to give safe and dependable service if operated according to the instructions.

  • Page 3: Specification

    I.SPECIFICATION MODEL CWS-80 CWS-160 CWS-230 Lifting capacity kg Wire rope top layer Lifting speed first layer m/min top layer 0.8 × 8 1.2 × 12 1.3 × 13 110V Motor kw×A 0.8 × 4 1.2 × 6 1.3 × 6.5...
  • Page 4 II. INSTALLMENT PRECAUTION 2.1 ENVIRONMENT PRECAUTION WARNING ●The following environmental conditions may result in the possible causes of winch trouble. ●Low temperature below -10 ●In a organic chemistry or high temperature above 40 C or explosive power conditions. humidity above 90% conditions. ※...
  • Page 5 2.3 MOUNTING The winch designed to be hanged or mounted on a firm or stable bar or a bracket CRH-0710 (as an option). When hanging, do not allow the body or load to be caught by any construction of frame, or other obstruction.

  • Page 6: Working Methods

    2.4.3 Switch cord connection 1)Insert the switch plug into the switch receptacle of the winch and tighten it by turning the locking ring clockwise. Be sure to hook the cord by a holder. 2)To extend the length of to switch cord EXC-0010 as an option, please adopt a switch extention cord.

  • Page 7: Handling Precaution

    IV. HANDLING PRECAUTION 4.1 ENVIORNMENT PRECAUTION WARNING ●Pay best attention to the following instruction . Obvious mistakes in operation may result in personal inquiry or equipment damage. ●Never try to lift a load ●Never hitch a ride on the more than the rated cap. hook, sling or load being moving.
  • Page 8 ●If having a counter rotation incurred, make sure to correct its rotation direction. ●Prior to lifting. Make sure to have a precise performance of brake. If any malfunction of brake happened, stop the operation immediately. ●When load suspended ●Wire rope with one in air, it will not or more of the following allow to be welding.

  • Page 9: Maintenance And Replacement

    V. MAINTENANCE AND REPLACEMENT 5.1 WIRE ROPE REPLACEMENT 5.1.1 Swivel hook ●Put a new wire rope through the hole of the round plate of swivel hook. ●Insert a sleeve pin through the thimble of wire rope. ●Insert a pin through the sleeve pin and bent it by a pliers. 5.1.2 Drum ●Let a new wire rope w/clamp through the limit lever and insert it into the hole of the drum.

  • Page 10: Oil Lubrication

    The initial lubricant should be changed after the first 10 hours of operation. Subsequent changes of 100 cc for CWS-80 and 250 cc for CWS-160/230 should be scheduled every 250 hours of operation or annually.
  • Page 11 ●However, if the limit lever is set too close to the winch body, it will cause serious damage to the limit lever and the winch body. ●A suggested distance (5) between the limit lever and winch body is as follows. MODEL CWS-80 CWS-160 CWS-230 DISTANCE 80-1000mm 70-900mm 70-900mm 5.6 REVERSE-WINDING PREVENTION DEVICE...

  • Page 12: Checking And Trouble Shooting

    VI. CHECKING AND TROUBLE SHOOTING 6.1 CHECKING REFERENCE. CLASSIFICATION OF CHECKS CHECKING CHECKING ITEMS PERIODICAL METHODS DAILY 3 MONTH/ 20 HOURS YEAR YEAR Visual ▲ Performance Decomposition check ▲ ●BRAKE Wearing of lining, and pressed plate Decomposition check ▲ Brake or escaping of spring ▲...

  • Page 13: Troubleshootings

    6-2. TROUBLE SHOOTINGS Checking the winch for smooth operation by pressing up and down button of push button switch. When winch fails to start after several attempts, or if any defective operation to be happened, check followings. OBSERVED POSSIBLE CAUSE SOLUTION ANOMALY No power...

  • Page 14: Wiring Diagram

    VII. WIRING DIAGRAM 7.1. FOR 100V~120V 7.2. FOR 200~240V...
  • Page 15 VIII. Replacement Parts List CWS-80...
  • Page 16 CWS-160/230...
  • Page 17 Limited Warranty This Limited Warranty is given by the COMEUP INDUSTRIES INC (the “Seller”) to the original purchaser (the “Purchaser”) of a Winch specified in this manual. This Limited Warranty is not transferable to any other party. The Seller takes the responsibility for all parts and components, with the...
