Comeup Cub 3 Manual

Introduction

Feature

Line pull:
Wire rope:
Brake:
Clutch:
Control:

Unpacking

．Winch assembly............................................................... 1 pc
．Handlebar rocker switch kit................................................ 1 pc
．4 way roller fairlead.......................................................... 1 pc
．Wire rope with hook except for PN 123321.........................
． Contactor pack ................................................................ 1 pc
Read this manual carefully
You should carefully read and understand this manual before operating it.
Careless winch operation may result in personal injury hazards or property
damage.
Information requesting or parts ordering
Please specify the followings information:
．Winch PN
．Part description
．Quantity for each part

Installation

Before using the winch, make sure all electrical
components have no corrosion or damaged; the
environment should be clear and dry.

Wire rope replacement

． It is very important that the winch will be mounted
1,361 kg / 3,000 lb wire rope first layer
4.8 mm x 15.2 m (3/16" x 50') galvanized aircraft A7 × 19
Mechanical and dynamic brake for 100% braking
Turn the shifter for rapid wire rope payout
Handlebar rocker switch to power the winch
Powersports Winch
Model:
．Serial number
．Replacement part number
Cub 3
PN: 123561 12V DC
PN: 123321 12V DC
1 pc
