Atx V 2.03 Power Supply Installation - SOLTEK 85ERV2 Manual

85ERV2 / 85ERV2-L

2-7 ATX V 2.03 Power Supply Installation

+12V Power Connector
+12V
+12V
PS/2 Mouse
(on top)
PS/2 K/B
(underside)
Rj 45
(on top)
USB0 (middle)
USB1 (underside)
Peripheral Power
Connector
VIA VT6103
PHY (LAN Controller)
1
CD1
AC'97
Codec
Audio Codec
Audio 1
14
WOL1
1 1
ATX V2.03 power supply is strongly recommended for mainboard run-
ning with 2GMHz or higher CPU.
To set up Power Supply on this series:
1. Connect the on-board Main Power Connector (20-pin) to the Main
Power Connector (20-pin) of an ATX Power Supply which can be
either of the latest version 2.03 or of earlier ATX format.
2. If you use an ATX Power Supply Version 2.03 or later, you can now
connect the on-board square-shaped +12V Connector to the square-
shaped +12V Connector of your ATX Power Supply. In this case, it is
not necessary for you to connect the on-board 4-pin Peripheral Power
Connector to your Power Supply.
3. If you use an ATX power Supply of an older version than V2.03, you
cannot find a square-shaped +12V Connector with your Power Supply;
you must then connect the on-board 4-pin Peripheral Power
Connector to the 4-pin Peripheral Power Connector of your Power
Supply.
3 1
GND
GND
4
2
RT1
VIA
P4x400A
AGP 4X/8X
PCI 1
PCI 2
VIA
PCI 3
VT8235
1
JP1
PCI 4
1
JBAT1
RT2
PCI 5
1
FAN3
IT8705F
LPC I/O
PCI 6
SCR1
FLASH BIOS
10 14
10
JUSB1
JUSB2
1
1
1
-12V
5SB
PWR OK
GND
+5V
GND
+5V
GND
+3.3V
+3.3V
Pin1
Main Power Connector
(20-pin)
Pin 1
Pin 4
Peripheral
Power Connector
24
+5V
+5V
-5V
GND
GND
GND
PS ON#
GND
-12V
+3.3V
Pin11
+12V
GND
GND
+5V
