1-4 Chipset System Block Diagram

AGP 4X/8X
AGP Slot
ATA 133/100/66
4 IDE
Devices
(Optional)
RJ45
PHY
(VT6103)
Fast Ethernet Interface
IR
FDD
Mouse/Keyboard
Serial Ports
Printer Port
Game/MIDI
H/Monitor
Intel Pentium 4 + VIA P4X400A + VIA VT8235 Diagram
Intel Pentium 4 CPU
System Bus 533/400MHz
VIA P4X400A
North Bridge
V Link
VT8235
South
Bridge
MII
LPC I/O
IT8705F
15
Chapter 1 Specification
DDR memory
Interface
DDR 333/266/200
(DDR 400 subject
to validation)
6 PCI Slots
PCI Bus
Audio
AC'97 2.2
Connectors
(6-channel)
USB Bus V2.0/1.1
BIOS
System
Memory
USB
Ports
