2-8 Jumper Settings

The following diagrams show the locations and settings of jumper blocks
on the mainboard.
PS/2 Mouse
(on top)
PS/2 K/B
(underside)
Rj 45
(on top)
USB0 (middle)
USB1 (underside)
Peripheral Power
Connector
VIA VT6103
PHY (LAN Controller)
1
CD1
AC'97
Codec
Audio Codec
Audio 1
14
WOL1
1 1
JBAT1
Clear CMOS
1
1-2 closed
(default)
To hold data
1
2-3 closed
To clear CMOS
RT1
VIA
P4x400A
AGP 4X/8X
PCI 1
PCI 2
VIA
PCI 3
VT8235
1
JP1
PCI 4
1
JBAT1
PCI 5
IT8705F
LPC I/O
PCI 6
SCR1
FLASH BIOS
10 14
10
JUSB1
JUSB2
1
1
1
Jp1:
CPU Clock Select
1
1-2 closed (default)
CPU Auto-detect
100 / 133MHz
1
2-3 closed
100MHz selected
1
Jumper open
133MHz selected
25
Chapter 2 Hardware Setup
Jp2
Flash ROM Write
Protection
1-2 closed
(default)
1
Enabled
2-3 closed
1
Disabled
RT2
1
FAN3
