4.7 cPCI-3520S Blade Assembly Layout

The dual-slot width cPCI-3520S Blade is comprised of the

cPCI-3520 single-slot main board and the DB-3UMC riser card,

expanding I/O connectivity with a XMC/PMC connector.

JN1

JN2

JN3

DB-3UMC

JN4

JN3

XMC connector

JN1/JN2/JN4

PCM connectors
