FALCON RIDGE KAW-3010TRANS-WD01 Installation Instructions And Care

Instructions for Installation and Care of 3010TRANS Soft Windshield
Notice: Do not smoke inside the cab or expose the enclosure to direct flames. Cab is Flammable.
1. Be sure to read these instructions thoroughly before unrolling and installing the
Falcon Ridge 3010 Soft Windshield. The installation is best done when the
temperature is 65 degrees F. or warmer.
2. Carefully unroll the Windshield on a large flat surface that is clean and free of dirt
or other material.
3. Check over the parts included in the carton with the parts list shown below:
Velcro Hook strips:
"
"
"
Windshield
4. Start installation by placing the 25" adhesive Velcro hook strip centered along the
top of the roll cage. You will want to place it halfway between the top and inside
of the bar, or diagonally toward the top inside. Now you can place the windshield
over the front and hang it from this position so that you can locate the remaining
Velcro positions.
5. Next note the correct position for the 17" latch strip on the brush guard at the
front of the Mule. Clean the area with Isopropyl alcohol, let dry and apply the
Velcro hook strip. Then attach the Cab to the strip around the brush guard.
6. Position and install the six (3 per side) 8" hook and loop strips on the left and
right sides of the roll cage on either side of the front window. Be certain to clean
the surfaces before applying the adhesive hook strips! First, apply all three strips
on one side of the roll cage then pull the window tightly toward the other side to
minimize waviness or wrinkles in the front window.
7. Finally, wrap the small straps in the top corners of the windshield around the roll
cage, overlapping the hook and loop the secure.
2515 Bypass Rd. Flemingsburg, KY 41041
606-845-7439
KAW-3010TRANS-WD01
2 each
"
6 each
"
1 each
"
1 each
1 each
3" long
8" long
17" long
25" long
