Instructions for Installation and Care of Bobcat 3400 Polaris Ranger
Notice: Do not smoke inside the cab or expose the enclosure to direct flames. Cab is Flammable.
Be sure to read these instructions thoroughly before opening and installing the enclosure. The installation is
best done when the temperature is 70 degrees F. or warmer. The temperature affects the adhesive Velcro, if
conditions prevent installing in warmer weather it helps to store the adhesive Velcro at room temperature
prior to installation.
1. Carefully open the carton and remove the enclosure on a large flat surface that is clean and free of dirt.
2. Check over the parts included in the carton with the parts list shown below:
Adhesive Velcro Hook Strips:
"
"
Snap Screw Studs
---------------------------------------------------------------------------
Adhesive Velcro Hook Strips:
"
"
"
---------------------------------------------------------------------------
31" Webbing Straps w/ Grommet
31" Webbing Straps w/Hook
45" Webbing Straps w/ Loop
Adhesive Velcro Hook Strips:
The cab for your Ranger is made up of 5 different components that work together to enclose your vehicle.
Install the cab in the following order.
1) Soft Doors
2) Rear Window
3) Poly Windshield
4) Top Cap
If any parts are damaged or missing please contact customer service at (606) 845-7439.
2515 Bypass Rd. Flemingsburg, KY 41041
606-845-7439
Full Cab Enclosure Fits Lexan
BC-3400-FC05 (NEW STYLE)
"
"
"
"
"
"
"
"
"
"
"
"
"
"
"
Soft Doors
18 each------------3"
2 each------------38"
15 each ( 1 extra )
Rear Window
8 each------------3"
1 each------------30"
1 each------------55"
Top Cap
2 each
2 each
2 each
2 each------------6"
Advertisement
Related Manuals for FALCON RIDGE BC-3400-FC05
Summary of Contents for FALCON RIDGE BC-3400-FC05
- Page 1 Instructions for Installation and Care of Bobcat 3400 Polaris Ranger Full Cab Enclosure Fits Lexan BC-3400-FC05 (NEW STYLE) Notice: Do not smoke inside the cab or expose the enclosure to direct flames. Cab is Flammable. Be sure to read these instructions thoroughly before opening and installing the enclosure. The installation is best done when the temperature is 70 degrees F.
- Page 2 Soft Doors: 1. Begin by holding the door up to the frame and attach it using the double-sided Velcro strips sewn perpendicular to the edge of the door. At each of the double-sided strips take one of the 3" adhesive Velcro strips and adhere it to the inside of the frame.
- Page 3 2. Next take the 38" adhesive Velcro strips and run it down the back of the roll cage facing towards the rear of the vehicle. Start at the bottom and work your way up the bar. You will see the double-sided Velcro tabs sewn along the back of the doors.
-
Page 4: Rear Window
REAR WINDOW: 4. Begin by placing the 30" adhesive Velcro strip centered across the top of the roll cage. Make sure to place them on top of the bar. 5. Next place the 55” strip across the bottom of the frame. It goes on the metal strip that faces the rear of the vehicle. - Page 5 TOP CAP: 9. After the windshield is installed take the soft Top Cap and put it over the top of the vehicle and make sure you have the on correctly. When put on correct the sides will match up with the shape of the roll cage.
- Page 6 Cab to either extreme hot or cold temperatures when storing. 3. A special cleaner conditioner is available from Falcon Ridge that will greatly increase the service life of the Cab Enclosure. In addition, if additional hook and loop sets are needed, they can also be ordered.
-
Page 7: Return Policy
Any returns submitted to Falcon Ridge without a return authorization number will be charged a 20% restocking fee. If ordered from one of Falcon Ridge’s many distributors, you must first call them and see what their return policy is. Once your item reaches our production facility, our customer satisfaction team will inspect your item to ensure unused, factory new condition.
