Instructions for Installation and Care of Arctic Cat / Textron Prowler Pro Soft Door Rear Kit
Notice: Do not smoke inside the cab or expose the enclosure to direct flames. Cab is Flammable.
Be sure to read these instructions thoroughly before opening and installing the enclosure. The installation is
best done when the temperature is 70 degrees F. or warmer. The temperature affects the adhesive Velcro, if
conditions prevent installing in warmer weather it helps to store the adhesive Velcro at room temperature
prior to installation.
1. Check over the parts included in the carton with the parts list shown below:
1" Adhesive Velcro Strip
2" Adhesive Velcro Strip
Snap studs
Door Panels
If any parts are damaged or missing please contact customer service at (606) 845-7439.
2. Begin by cleaning the roll cage and plastic that surrounds the doors. Using rubbing alcohol is preferable. This step
is very important for the Velcro strips to properly adhere.\
2515 Bypass Rd. Flemingsburg, KY 41041
2 each
2 each
"
"
2 each
"
"
2 each
4 each
4 each
11 each ( 1 extra )
2 each
606-845-7439
AC-PRO-SDK01
16" long
5" long
8" long
20" long
32" long
34" long
Advertisement
Related Manuals for FALCON RIDGE AC-PRO-SDK01
Summary of Contents for FALCON RIDGE AC-PRO-SDK01
- Page 1 606-845-7439 Instructions for Installation and Care of Arctic Cat / Textron Prowler Pro Soft Door Rear Kit AC-PRO-SDK01 Notice: Do not smoke inside the cab or expose the enclosure to direct flames. Cab is Flammable. Be sure to read these instructions thoroughly before opening and installing the enclosure. The installation is best done when the temperature is 70 degrees F.
- Page 2 3. Now start installation by placing the 2" adhesive Velcro strips around the outside edges of the upper door frame. Starting at the front of the frame first place the 34" strip as shown in the photo below. 4. Next place the 32" strip across the top of the frame as shown below.
- Page 3 5. Next place the5" strip in the rear corner as shown below. 6. Next place the 18" strip down the back of the cage as shown in the photo on the next page.
- Page 4 7. After all the Velcro is in place take the door and place it on the vehicle. The following series of photos show how it should look after being installed.
- Page 5 8. Next attach the 8” adhesive Velcro strip to the bottom of the front top portion of the door as shown in the photos below.
- Page 6 9. Now take the 18” Strip that is 1” wide and place it on the inside front portion of the factory door. Then take the bottom front section of the soft door and wrap it around the factory door and attach the two together as shown in the photos below.
- Page 7 Cab to either extreme hot or cold temperatures when storing. 3. A special cleaner conditioner is available from Falcon Ridge that will greatly increase the service life of the Cab Enclosure. In addition, if additional hook and loop sets are needed, they can also be ordered.
-
Page 8: Return Policy
Any returns submitted to Falcon Ridge without a return authorization number will be charged a 20% restocking fee. If ordered from one of Falcon Ridge’s many distributors, you must first call them and see what their return policy is. Once your item reaches our production facility, our customer satisfaction team will inspect your item to ensure unused, factory new condition.
