FALCON RIDGE KAW-3010TRANS-FC03 Instructions For Installation And Care

Caution: Do not smoke inside the cab or expose the enclosure to direct flames. Product is FLAMMABLE.
Be sure to read these instructions thoroughly before opening and installing the enclosure. The installation is
best done when the temperature is 70
adhesive Velcro strips inside just before installation is recommended.
1. Carefully open the carton and remove the rolled-up cab enclosure on a large flat surface that is clean and
free of dirt or other material that may soil the cab or scratch the clear vinyl windows. Check over the
parts included in the carton with the parts list shown below:
Velcro hook strips
Velcro hook strips
Velcro hook strips
Velcro hook strips
Velcro hook strips
Velcro hook strips
Screw snaps
Cab enclosure
2. Open up the enclosure; it will be in 4 separate pieces when removed from the packaging. With the help
of another person drape the top of the enclosure over the top of the roll cage and arrange into the correct
position.
3. Working your way to the rear of the roll cage, fit the enclosure into position. Wrap the bars with the 6"
adhesive hook strips directly above the air intake vents on both sides of the roll cage frame. Firmly grasp
the rear corners of the windshield/top and pull them down to the Velcro; wrap the double-sided Velcro
strips around the hook strips you previously applied to the roll cage tube.
4. At this point get help from a friend; with both of you pulling down on both sides of the front of the
enclosure (the long strip portions), use a crayon or similar non-permanent marker to mark the locations
of the Velcro tab sewn to the bottom of the front enclosure strips onto the frame tubes. Apply a 10"
adhesive strip onto the roll cage tubes on both sides of the frame, lengthwise on the inside of the tubes at
the bottom just above the attachment brackets and facing each other. Attach the corresponding Velcro
tab at the bottoms of the front enclosure strips to the hook strips previously applied to the insides of the
bottoms of the frame tubes. Now apply the 8" adhesive hook strips to the insides of the roll cage tubes at
the next Velcro tab up, in the same manner as you did with the 10" strips. Repeat this step with the 4"
Velcro tab above that, and then with the 6" tab at the top. Attach the rest of the Velcro tabs to the hook
strips on the frame tubes. Finally locate the double-sided Velcro strips at the center roll cage tube but do
2515 Bypass Rd
(606) 845-7439
Instructions for Installation and Care of
Kawasaki 3010 Trans
Full Cab Enclosure w/Polycarbonate Windshield
KAW-3010TRANS-FC03
°
F or warmer. If installed outside and in the cold weather, warming the
2 each
14 each
2 each
2 each
2 each
1 each
11 each (1 extra)
1 each
Flemingsburg, KY 41041
4" long
6" long
8" long (1" wide)
8" long
10" long
43" long
