GPS Status
No Satellite Lock
Full Lock
Antenna A only SAT Lock
If you have enabled a DGPS mode, it is indicated by the middle indicator light with one of the following messages.
DGPS Mode
WAAS, SBAS or EGNOS Differential correction
40 cm Differential correction from Base station
Logged File name:
When you have an SD card inserted, the file name of the logged file appears on the screen while the VBOX II logs data.

Front Panel Buttons

You can configure VBOX IISX units with the front panel buttons so that you can do the configuration without the need for
a computer. You can also configure it via the
From the main screen, press the '■' button to enter the configuration screen.
Note: When you enter the configuration screen, the VBOX IISX will stop the logging to the SD card. When you
are using it in continuous logging mode, you have to make sure that you push the '■' button before you
remove the SD card so you don't lose any of your data.
In the configuration screen, you can press the '◄' and '►' buttons to highlight the previous or next choice in any
menu and press '■' to select the highlighted option. Most of the main menus contain sub-menus. For example, the
Settings and Setup Antennas menus contain separate menus for each parameter.
Left Position
-
OK
-
VBOX Setup
https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/VBOX_II/VBOX_IISX_20_Hz_GPS_Data_Logger/
User_Guide%3A_VBOX_IISX_Data_Logger/03_Front_Panel_%E2%80%93_VBOX_IISX
Display notifications
Middle Position
SAT (flashing)
-
RTK (flashing)
Display Notification
WAAS
40 cm
Software.
Right Position
RTK (flashing)
-
RTK (flashing)
