Outputs: Analogue Setup Menu (Channel 1 and 2)
OUTPUT
VALUE @ +5V
VALUE @ 0V
VALUE @ -5V
TEST
EXIT
https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/VBOX_II/VBOX_IISX_20_Hz_GPS_Data_Logger/
User_Guide%3A_VBOX_IISX_Data_Logger/03_Front_Panel_%E2%80%93_VBOX_IISX
Press '■' and then use the '◄' and '►' buttons to
associate either of the following channels SPEED, LAT
ACC and LONG ACC to the Analogue output. Press
'■' to confirm.
Press '■' and use the '◄' and '►' buttons to set the
value to represent +5 V. Press '■' to confirm.
Available ranges:
1 – 400 km/h (in steps of 1 km/h) SPEED
-1 to 2 g (in steps of 0.1g) LAT ACC
-1 to 2 g (in steps of 0.1g) LONG ACC
This setting is only available when you have set the
output to SPEED.
Press '■' and use the '◄' and '►' buttons to set the
velocity to represent 0 V. Press '■' to confirmyour
selection.
0-399 km/h (in steps of 1 km/h)
This setting is only available when you have set the
output to LAT ACC or LONG ACC.
Press '■' and then use the '◄' and '►' buttons to set the
value to represent -5 V. Then press '■' to confirm.
Available ranges:
-2 to 1 g (in steps of 0.1g) LAT ACC
-2 to 1 g (in steps of 0.1g) LONG ACC
Press '■' and use the '◄' and '►' buttons to set a test
value that the Analogue output will simulate. Press '■' to
quit.
Press '■' to exit the setup menu and save the settings in
EEPROM.
