Connector 7 - USB
(Setup / Upgrade)
PIN
1
2
3
4
Chassis
User_Guide%3A_VBOX_IISX_Data_Logger/09_Technical_Properties_%E2%80%93_VBOX_IISX/PIN-OUTS%3A_VBOX_IISX
I/O
I/O
I/O
I/O
I/O
I/O
https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/VBOX_II/VBOX_IISX_20_Hz_GPS_Data_Logger/
Function
Power
USB-
USB+
Ground
Ground
33
