Outputs
Identifier type
Data available
Analogue
Voltage range
Default setting *
Accuracy
Update rate
Inputs
CAN Bus
VCI CAN mode
Racelogic modules mode
https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/VBOX_II/VBOX_IISX_20_Hz_GPS_Data_Logger/
User_Guide%3A_VBOX_IISX_Data_Logger/09_Technical_Properties_%E2%80%93_VBOX_IISX/
baud rate
Standard 11 bit or extended 2.0 B
Satellites in view, Latitude, Longitude, Velocity,
Heading, Altitude, Vertical velocity, Distance,
Longitudinal acceleration, Lateral acceleration, Distance
from the trigger, Trigger time, Trigger velocity, True
heading.
–5 V to +5 V DC
Velocity
0.0125 Volts per km/h (0 to 400 km/h)
0.1 km/h
20 Hz
Format; Motorola
Up to 16 channels from any external CAN module
Up to 20 channels from any combination of ADC02,
ADC03, FIM02, TC8, Yaw sensor or CAN01
